Installation

Install with pip / uv:

# pip
pip install git+https://github.com/RealHand-Robotics/realbot-python-sdk.git

# uv
uv add "realhand @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

Or install explicitly from the Git repository:

# pip
pip install git+https://github.com/RealHand-Robotics/realbot-python-sdk.git

# uv
uv add "realhand @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

Optional Dependencies

Kinetix (Kinematics, required for arms)

Arms (A7 / A7 Lite) rely on Pinocchio for kinematics and require an extra installation:

# pip (Linux / macOS)
pip install "realhand[kinetix] @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

# uv
uv add "realhand[kinetix] @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

Windows users: Pinocchio does not support installation via pip on Windows. Use Conda instead:

conda install pinocchio -c conda-forge

If you only use dexterous hands (L6 / L20Lite / L20 / L25, etc.), this dependency is not required.

Quick Start

Connect to a Dexterous Hand

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Control and read the hand
    pass

Use a with statement to ensure resources are released correctly.

Control Joint Angles

Set target angles for the 6 joints (range 0-100):

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Open the hand
    hand.angle.set_angles([100, 50, 100, 100, 100, 100])

    # Close into a fist
    hand.angle.set_angles([0, 0, 0, 0, 0, 0])

Joint order: [thumb_flex, thumb_abd, index, middle, ring, pinky]

Read Angles

with L6(side="left", interface_name="can0") as hand:
    # Blocking read
    data = hand.angle.get_blocking(timeout_ms=100)
    print(f"Current angles: {data.angles.to_list()}")

    # Access a single joint
    print(f"Index finger: {data.angles.index}")

Read Force Sensors

Get force sensor data from all 5 fingers:

with L6(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)

    # Access per-finger data
    print(f"Thumb: {data.thumb.values.shape}")  # (12, 6)
    print(f"Index: {data.index.values.shape}")

Streaming Reads

Continuously receive data through the unified event stream. Polling starts automatically at initialization with default intervals (angles at 60 Hz, force sensors at 30 Hz). You can override that by calling start_polling() manually:

from realhand.hand.l6 import SensorSource, AngleEvent

with L6(side="left", interface_name="can0") as hand:
    # Default polling has already started automatically (angle + force sensor)
    # Call start_polling() again if you want custom settings
    hand.start_polling({SensorSource.ANGLE: 0.1})

    for event in hand.stream():
        match event:
            case AngleEvent(data=data):
                print(f"Angles: {data.angles.to_list()}")

        if should_stop():
            break

    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L6
import time

with L6(side="left", interface_name="can0") as hand:
    # Set speed
    hand.speed.set_speeds([50, 50, 50, 50, 50, 50])

    # Open
    hand.angle.set_angles([100, 50, 100, 100, 100, 100])
    time.sleep(1)

    # Close
    hand.angle.set_angles([0, 0, 0, 0, 0, 0])
    time.sleep(1)

    # Read state
    angles = hand.angle.get_blocking()
    temps = hand.temperature.get_blocking()

    print(f"Angles: {angles.angles.to_list()}")
    print(f"Temperature: {temps.temperatures.to_list()} °C")

Next Steps

• Basics - Understand the SDK architecture
• Angle Control - Detailed API
• Force Sensors - Force sensor details

Basics

Architecture Overview

The SDK uses a modular design. All features are accessed through the main class:

L6
├── hand.angle          # Angle control
├── hand.speed          # Speed control
├── hand.torque         # Torque control
├── hand.current        # Current reading
├── hand.temperature    # Temperature reading
├── hand.force_sensor   # Force sensors
├── hand.fault          # Fault handling
└── hand.version        # Version information

Calling Convention

All features are called through hand.module.method():

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    hand.angle.set_angles([50, 50, 50, 50, 50, 50])
    hand.speed.set_speeds([100, 100, 100, 100, 100, 100])

    data = hand.temperature.get_blocking()

Type Safety

The SDK provides typed data classes with IDE autocompletion support:

from realhand import L6
from realhand.hand.l6 import L6Angle

with L6(side="left", interface_name="can0") as hand:
    # Use a data class (recommended, with type hints)
    angle = L6Angle(thumb_flex=50, thumb_abd=30, index=60, middle=60, ring=60, pinky=60)
    hand.angle.set_angles(angle)

    # Or use a list (more concise)
    hand.angle.set_angles([50, 30, 60, 60, 60, 60])

Data class fields:

Data Reading Modes

Blocking Read

Send a request and wait for a response:

data = hand.angle.get_blocking(timeout_ms=100)

Cached Read

Get the most recently received data without blocking:

data = hand.angle.get_snapshot()
if data is not None:
    print(data.angles)

Streaming Read

Continuously receive data from the unified event stream:

from realhand.hand.l6 import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

for event in hand.stream():
    match event:
        case AngleEvent(data=data):
            print(data.angles)
    if should_stop():
        break

hand.stop_polling()
hand.stop_stream()

Snapshot

Get the latest cached values from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.temperature)  # TemperatureData | None

Resource Management

Use a with statement to manage resources automatically:

with L6(side="left", interface_name="can0") as hand:
    # Use the hand
    pass
# Resources are released automatically

Or manage the lifecycle manually:

hand = L6(side="left", interface_name="can0")
try:
    # Use the hand
    pass
finally:
    hand.close()

Exception Handling

from realhand import L6
from realhand.exceptions import TimeoutError, ValidationError

with L6(side="left", interface_name="can0") as hand:
    try:
        data = hand.angle.get_blocking(timeout_ms=100)
    except TimeoutError:
        print("Read timed out")
    except ValidationError as e:
        print(f"Invalid parameter: {e}")

Joint Indexing

All 6-joint modules use the same index order:

CAN Bus

L6/O6 dexterous hands communicate over the CAN bus. The interface_type parameter in the constructor selects the CAN adapter type.

Constructor Parameters

from realhand import L6

hand = L6(
    side="left",  # "left" or "right"
    interface_name="can0",  # Interface name
    interface_type="socketcan",  # Adapter type
)

Linux (SocketCAN)

Linux uses SocketCAN by default, so you do not need to specify interface_type.

hand = L6(side="left", interface_name="can0")

Configure the CAN interface:

sudo ip link set can0 type can bitrate 1000000
sudo ip link set can0 up

To connect multiple CAN interfaces: Linux names interfaces in creation order, so depending on the order in which CAN adapters are connected to the control board, they will be named can0, can1, can2, and so on. You can bring up multiple CAN interfaces by running the following commands in sequence:

sudo ip link set can0 type can bitrate 1000000 && sudo ip link set can0 up && \
sudo ip link set can1 type can bitrate 1000000 && sudo ip link set can1 up && \
sudo ip link set can2 type can bitrate 1000000 && sudo ip link set can2 up
# ...

Windows (PCAN)

Use a PCAN adapter on Windows:

hand = L6(side="left", interface_name="PCAN_USBBUS1", interface_type="pcan")

For other adapter types, see the python-can documentation.

L6 Dexterous Hand

Quick Start

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles((10, 20, 30, 40, 50, 60))

    # Read angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(data.angles)

Constructor parameters

Joint Definition

Functional Modules

Unified Streaming Reads

L6 provides a unified event stream interface. Use hand.stream() and hand.start_polling() to retrieve data from all sensors. Polling starts automatically at initialization using default intervals (angles at 60 Hz, force sensors at 30 Hz), so you do not need to call start_polling() manually.

from realhand import L6
from realhand.hand.l6 import SensorSource, AngleEvent, TemperatureEvent

with L6(side="left", interface_name="can0") as hand:
    # You can set multiple sensors and polling intervals (seconds)
    # Calling start_polling() again overrides the previous settings
    hand.start_polling({SensorSource.ANGLE: 0.05, SensorSource.TEMPERATURE: 1.0})

    for event in hand.stream():
        match event:
            case AngleEvent(data=ad):
                print(f"Angles: {ad.angles.to_list()}")
            case TemperatureEvent(data=td):
                print(f"Temperature: {td.temperatures.to_list()}")

    hand.stop_polling()
    hand.stop_stream()

Available SensorSource values and default rates

Snapshot

Get the latest cached data from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.temperature)  # TemperatureData | None

Angle Control

Use hand.angle to control and read the 6 joint motor angles of the L6 dexterous hand.

• Angle range: 0-100
• Unit: Unitless, mapped to actual joint motor angles

Set Angles

from realhand import L6
from realhand.hand.l6 import L6Angle

# Using a list
hand.angle.set_angles([50.0, 30.0, 60.0, 60.0, 60.0, 60.0])

# Using an L6Angle object
angles = L6Angle(
    thumb_flex=50.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index=60.0,  # Index finger
    middle=60.0,  # Middle finger
    ring=60.0,  # Ring finger
    pinky=60.0,  # Pinky
)
hand.angle.set_angles(angles)

Read Angles

Blocking Read

from realhand import L6
from realhand.exceptions import TimeoutError

try:
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.angles.thumb_flex}")
    print(f"All angles: {data.angles.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.angle.get_snapshot()
if data:
    print(f"Angles: {data.angles.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

for event in hand.stream():
    match event:
        case AngleEvent(data=data):
            print(f"Angles: {data.angles.to_list()}")

hand.stop_polling()
hand.stop_stream()

Complete Example

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([0.0, 0.0, 0.0, 0.0, 0.0, 0.0])

    # Read current angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Current angles: {data.angles.to_list()}")

    # Incremental motion
    for i in range(0, 101, 10):
        hand.angle.set_angles([float(i)] * 6)

Speed Control

Control the motion speed of each joint motor on the L6 dexterous hand.

Set Speed

hand.speed.set_speeds(speeds)

Set the target speed for all 6 joint motors.

Parameter:

• speeds: An L6Speed instance or a 6-element list, with values in the range 0-100 (unitless)

Finger order: thumb flexion, thumb abduction, index finger, middle finger, ring finger, pinky

Examples

List Form

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Set all fingers to medium speed
    hand.speed.set_speeds([50.0, 50.0, 50.0, 50.0, 50.0, 50.0])

L6Speed Form

from realhand import L6
from realhand.hand.l6 import L6Speed

with L6(side="left", interface_name="can0") as hand:
    # Thumb slow, other fingers fast
    speed = L6Speed(
        thumb_flex=30.0, thumb_abd=30.0, index=80.0, middle=80.0, ring=80.0, pinky=80.0
    )
    hand.speed.set_speeds(speed)

Torque Control

Overview

Use hand.torque for torque control. It supports setting target torque values and reading the current torque.

Torque values range from 0-100 (unitless, representing the relative torque percentage of the joint motors) for the 6 joint motors of the L6 dexterous hand:

Set Torque

# Using a list
hand.torque.set_torques([50.0, 30.0, 60.0, 60.0, 60.0, 60.0])

# Using an L6Torque object
from realhand.hand.l6 import L6Torque

target = L6Torque(
    thumb_flex=50.0, thumb_abd=30.0, index=60.0, middle=60.0, ring=60.0, pinky=60.0
)
hand.torque.set_torques(target)

Read Torque

Blocking Read

Send a request and wait for the response:

from realhand.exceptions import TimeoutError

try:
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.torques.thumb_flex}")
    print(f"Index finger: {data.torques.index}")
except TimeoutError:
    print("Read timed out")

Cached Read

Get the most recent cached value without blocking:

data = hand.torque.get_snapshot()
if data:
    print(f"Torque: {data.torques.to_list()}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, TorqueEvent

hand.start_polling({SensorSource.TORQUE: 0.05})

for event in hand.stream():
    match event:
        case TorqueEvent(data=data):
            print(f"Torque: {data.torques.to_list()}")

hand.stop_polling()
hand.stop_stream()

Examples

Full Control Flow

from realhand import L6
from realhand.hand.l6 import L6Torque

with L6(side="left", interface_name="can0") as hand:
    # Set torque
    hand.torque.set_torques([50.0, 30.0, 60.0, 60.0, 60.0, 60.0])

    # Blocking read of current torque
    data = hand.torque.get_blocking(timeout_ms=200)
    print(f"Current torque: {data.torques.to_list()}")

Real-Time Monitoring

from realhand import L6
from realhand.hand.l6 import SensorSource, TorqueEvent

with L6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TORQUE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TorqueEvent(data=data):
                    if data.torques.index > 80:
                        print("Index joint motor torque is too high")
                        break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Current Reading

from realhand import L6

Read the real-time current of the six L6 joint motors in mA.

Overview

Use hand.current to read current values. Three access patterns are supported:

Read Current

Blocking Read

Send a request and wait for a response:

data = hand.current.get_blocking(timeout_ms=500)

# Access per-joint current values (mA)
print(data.currents.thumb_flex)  # Thumb flexion
print(data.currents.thumb_abd)  # Thumb abduction
print(data.currents.index)  # Index finger
print(data.currents.middle)  # Middle finger
print(data.currents.ring)  # Ring finger
print(data.currents.pinky)  # Pinky

# Index access
print(data.currents[0])  # thumb_flex

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Exception:

• TimeoutError: No response received before timeout

Cached Read

Get the most recent cached data without sending a request:

data = hand.current.get_snapshot()
if data:
    print(f"Current: {data.currents.to_list()}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, CurrentEvent

hand.start_polling({SensorSource.CURRENT: 0.05})

for event in hand.stream():
    match event:
        case CurrentEvent(data=data):
            print(f"Current: {data.currents.to_list()}")

hand.stop_polling()
hand.stop_stream()

Examples

Detect Overcurrent

from realhand import L6
from realhand.hand.l6 import SensorSource, CurrentEvent

with L6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.CURRENT: 0.05})

    try:
        for event in hand.stream():
            match event:
                case CurrentEvent(data=data):
                    for i, current in enumerate(data.currents.to_list()):
                        if current > 1000:
                            print(f"Warning: joint {i} current is too high ({current} mA)")
    finally:
        hand.stop_polling()
        hand.stop_stream()

Log Current Data

import time
from realhand import L6
from realhand.hand.l6 import SensorSource, CurrentEvent

with L6(side="left", interface_name="can0") as hand:
    records = []
    start = time.time()
    hand.start_polling({SensorSource.CURRENT: 0.1})

    try:
        for event in hand.stream():
            match event:
                case CurrentEvent(data=data):
                    records.append(
                        {
                            "time": data.timestamp - start,
                            "currents": data.currents.to_list(),
                        }
                    )
            if time.time() - start > 5:  # Record for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

    print(f"Collected {len(records)} records")

Temperature Reading

Overview

Use hand.temperature to read the temperature data of the 6 L6 joint motors in °C.

Temperature fields

Read Temperature

Blocking Read

data = hand.temperature.get_blocking(timeout_ms=500)
print(f"Thumb temperature: {data.temperatures.thumb_flex}°C")

Parameter

• timeout_ms: Timeout in milliseconds, default 100

Return value

• TemperatureData: Contains temperatures and timestamp

Exception

• TimeoutError: No response before timeout

Cached Read

Read the most recent cached temperature data without blocking.

data = hand.temperature.get_snapshot()
if data:
    print(f"Temperature: {data.temperatures.to_list()}")

Return value

• TemperatureData or None if no cached data is available

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, TemperatureEvent

hand.start_polling({SensorSource.TEMPERATURE: 0.1})

for event in hand.stream():
    match event:
        case TemperatureEvent(data=data):
            print(f"Temperature: {data.temperatures.to_list()}")

hand.stop_polling()
hand.stop_stream()

Examples

Read All Joint Temperatures

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    data = hand.temperature.get_blocking(timeout_ms=500)

    # Access by field
    print(f"Thumb flexion: {data.temperatures.thumb_flex}°C")
    print(f"Index finger: {data.temperatures.index}°C")

    # Convert to list
    temps = data.temperatures.to_list()
    print(f"All temperatures: {temps}")

    # Index access
    print(f"First joint motor: {data.temperatures[0]}°C")

Temperature Monitoring

from realhand import L6
from realhand.hand.l6 import SensorSource, TemperatureEvent

with L6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TEMPERATURE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TemperatureEvent(data=data):
                    for i, temp in enumerate(data.temperatures.to_list()):
                        if temp > 60.0:
                            print(f"Warning: joint motor {i} is overheating ({temp}°C)")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Force Sensors

The L6 dexterous hand is equipped with force sensors on 5 fingers (thumb, index, middle, ring, pinky). It supports both blocking and cached reads.

Overview

Use hand.force_sensor to access force sensor data:

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking()

Data Structures

ForceSensorData - sensor data for one finger:

• values: A NumPy array of shape (12, 6) with dtype uint8
• timestamp: Unix timestamp

AllFingersData - data for all 5 fingers:

• thumb, index, middle, ring, pinky: the ForceSensorData for each finger

Read Data

Blocking Read

data = hand.force_sensor.get_blocking(timeout_ms=1000)
print(data.thumb.values)  # Thumb data
print(data.index.values)  # Index data

Exceptions: TimeoutError (timeout), ValidationError (invalid parameter)

Cached Read

Get the most recently received data without blocking:

data = hand.force_sensor.get_snapshot()
if data:
    print(f"Thumb: {data.thumb.values[0]}")
    print(f"Index: {data.index.values[0]}")

Return value: AllFingersData or None if any finger is missing data

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, ForceSensorEvent

hand.start_polling({SensorSource.FORCE_SENSOR: 0.1})

for event in hand.stream():
    match event:
        case ForceSensorEvent(data=data):
            print(data.thumb.values)

hand.stop_polling()
hand.stop_stream()

Examples

Blocking Read for All Fingers

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(f"Thumb: {data.thumb.values.shape}")  # (12, 6)
    print(f"Index: {data.index.values.shape}")

Stream for a Fixed Duration

import time
from realhand import L6
from realhand.hand.l6 import SensorSource, ForceSensorEvent

with L6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FORCE_SENSOR: 0.05})
    start = time.time()

    try:
        for event in hand.stream():
            match event:
                case ForceSensorEvent(data=data):
                    print(f"Thumb: {data.thumb.values[0]}")
            if time.time() - start > 5:  # Collect for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Fault Handling

Fault detection and clearing for the L6 dexterous hand.

Overview

Use hand.fault to access fault-related functions:

• Clear fault codes
• Read fault status in blocking or cached mode

Fault Code Table

Clear Faults

hand.fault.clear_faults()

Clear fault codes on all joints.

Read Faults

Blocking Read

data = hand.fault.get_blocking(timeout_ms=500)

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Return value: FaultData, containing:

• faults: L6Fault fault data
• timestamp: Timestamp

Exception:

• TimeoutError: No response before timeout

Cached Read

data = hand.fault.get_snapshot()

Returns the latest cached fault data, or None if no data is available.

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l6 import SensorSource, FaultEvent

hand.start_polling({SensorSource.FAULT: 0.2})

for event in hand.stream():
    match event:
        case FaultEvent(data=data):
            if data.faults.has_any_fault():
                for code in data.faults.to_list():
                    if code.has_fault():
                        print(code.get_fault_names())

hand.stop_polling()
hand.stop_stream()

Fault Data

L6Fault fields

L6Fault methods

# Check whether any fault exists
faults.has_any_fault()  # -> bool

# Convert to a list
faults.to_list()  # -> list[FaultCode]

# Index access
faults[0]  # thumb_flex

FaultCode methods

# Check whether a single joint has a fault
faults.thumb_flex.has_fault()  # -> bool

# Get fault names
faults.thumb_flex.get_fault_names()  # -> list[str]

Examples

Check and Clear Faults

from realhand import L6

with L6(side="left", interface_name="can0") as hand:
    # Read fault status
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        print("Fault detected:")
        if data.faults.thumb_flex.has_fault():
            print(f"  Thumb flexion: {data.faults.thumb_flex.get_fault_names()}")
        if data.faults.index.has_fault():
            print(f"  Index finger: {data.faults.index.get_fault_names()}")

        # Clear faults
        hand.fault.clear_faults()
    else:
        print("No faults")

Continuous Monitoring

from realhand import L6
from realhand.hand.l6 import SensorSource, FaultEvent

with L6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FAULT: 0.2})

    try:
        for event in hand.stream():
            match event:
                case FaultEvent(data=data):
                    if data.faults.has_any_fault():
                        for code in data.faults.to_list():
                            if code.has_fault():
                                print(code.get_fault_names())
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Version Information

Read version information for the L6 dexterous hand.

Overview

Use hand.version to access version-related functionality:

• Read complete device information, including serial number and PCB / firmware / mechanical versions

Read Device Information

hand.version.get_device_info() -> DeviceInfo

Returns a DeviceInfo object containing:

The Version object has major, minor, and patch fields, and its string format is V{major}.{minor}.{patch}.

Exception:

• TimeoutError: Request timed out

Example

Read Device Information

from realhand import L6

hand = L6(channel="can0", hand_id=1)

info = hand.version.get_device_info()
print(f"Serial number: {info.serial_number}")
print(f"Firmware version: {info.firmware_version}")

hand.close()

L20Lite Dexterous Hand

Quick Start

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([50, 30, 60, 60, 60, 60, 20, 20, 20, 20])

    # Read angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(data.angles)

Constructor parameters

Joint Definition

Functional Modules

Unified Streaming Reads

L20Lite provides a unified event stream interface. Use hand.stream() and hand.start_polling() to retrieve data from all sensors. Polling starts automatically at initialization using default intervals (angles at 60 Hz, force sensors at 30 Hz), so you do not need to call start_polling() manually.

from realhand import L20lite
from realhand.hand.l20lite import SensorSource, AngleEvent, TemperatureEvent

with L20lite(side="left", interface_name="can0") as hand:
    # You can set multiple sensors and polling intervals (seconds)
    # Calling start_polling() again overrides the previous settings
    hand.start_polling({SensorSource.ANGLE: 0.05, SensorSource.TEMPERATURE: 1.0})

    for event in hand.stream():
        match event:
            case AngleEvent(data=ad):
                print(f"Angles: {ad.angles.to_list()}")
            case TemperatureEvent(data=td):
                print(f"Temperature: {td.temperatures.to_list()}")

    hand.stop_polling()
    hand.stop_stream()

Available SensorSource values and default rates

Snapshot

Get the latest cached data from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.speed)  # SpeedData | None
print(snap.torque)  # TorqueData | None
print(snap.temperature)  # TemperatureData | None
print(snap.force_sensor)  # AllFingersData | None

Angle Control

Use hand.angle to control and read the 10 joint motor angles of the L20Lite dexterous hand.

• Angle range: 0-100
• Unit: Unitless, mapped to actual joint motor angles

Set Angles

from realhand import L20lite
from realhand.hand.l20lite import L20liteAngle

# Using a list
hand.angle.set_angles([50.0, 30.0, 60.0, 60.0, 60.0, 60.0, 20.0, 20.0, 20.0, 20.0])

# Using an L20liteAngle object
angles = L20liteAngle(
    thumb_flex=50.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index_flex=60.0,  # Index flexion
    middle_flex=60.0,  # Middle flexion
    ring_flex=60.0,  # Ring flexion
    pinky_flex=60.0,  # Pinky flexion
    index_abd=20.0,  # Index abduction
    ring_abd=20.0,  # Ring abduction
    pinky_abd=20.0,  # Pinky abduction
    thumb_yaw=20.0,  # Thumb rotation
)
hand.angle.set_angles(angles)

Read Angles

Blocking Read

from realhand import L20lite
from realhand.exceptions import TimeoutError

try:
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.angles.thumb_flex}")
    print(f"All angles: {data.angles.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.angle.get_snapshot()
if data:
    print(f"Angles: {data.angles.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20lite import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

try:
    for event in hand.stream():
        match event:
            case AngleEvent(data=data):
                print(f"Angles: {data.angles.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0])

    # Read current angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Current angles: {data.angles.to_list()}")

    # Incremental motion
    for i in range(0, 101, 10):
        hand.angle.set_angles([float(i)] * 10)

Speed Control

Use hand.speed to control and read the motion speed of each joint motor on the L20Lite dexterous hand.

• Speed range: 0-100
• Unit: Unitless, mapped to actual motor speed

Set Speed

from realhand import L20lite
from realhand.hand.l20lite import L20liteSpeed

# Using a list
hand.speed.set_speeds([50.0, 50.0, 50.0, 50.0, 50.0, 50.0, 50.0, 50.0, 50.0, 50.0])

# Using an L20liteSpeed object
speeds = L20liteSpeed(
    thumb_flex=30.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index_flex=80.0,  # Index flexion
    middle_flex=80.0,  # Middle flexion
    ring_flex=80.0,  # Ring flexion
    pinky_flex=80.0,  # Pinky flexion
    index_abd=50.0,  # Index abduction
    ring_abd=50.0,  # Ring abduction
    pinky_abd=50.0,  # Pinky abduction
    thumb_yaw=50.0,  # Thumb rotation
)
hand.speed.set_speeds(speeds)

Read Speed

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Thumb flexion speed: {data.speeds.thumb_flex}")
    print(f"All speeds: {data.speeds.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.speed.get_snapshot()
if data:
    print(f"Speed: {data.speeds.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20lite import SensorSource, SpeedEvent

hand.start_polling({SensorSource.SPEED: 0.1})

try:
    for event in hand.stream():
        match event:
            case SpeedEvent(data=data):
                print(f"Speed: {data.speeds.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20lite
from realhand.hand.l20lite import L20liteSpeed

with L20lite(side="left", interface_name="can0") as hand:
    # Thumb slow, other fingers fast
    speeds = L20liteSpeed(
        thumb_flex=20.0,
        thumb_abd=20.0,
        index_flex=80.0,
        middle_flex=80.0,
        ring_flex=80.0,
        pinky_flex=80.0,
        index_abd=60.0,
        ring_abd=60.0,
        pinky_abd=60.0,
        thumb_yaw=60.0,
    )
    hand.speed.set_speeds(speeds)

    # Read current speed
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Current speed: {data.speeds.to_list()}")

    # Observe the effect after setting angles
    hand.angle.set_angles([100.0] * 10)

Torque Control

Use hand.torque to control and read the torque of the 10 joint motors on the L20Lite dexterous hand.

• Torque range: 0-100
• Unit: Unitless percentage

Set Torque

from realhand import L20lite
from realhand.hand.l20lite import L20liteTorque

# Using a list
hand.torque.set_torques([50.0, 50.0, 60.0, 60.0, 60.0, 60.0, 30.0, 30.0, 30.0, 30.0])

# Using an L20liteTorque object
torques = L20liteTorque(
    thumb_flex=50.0,  # Thumb flexion
    thumb_abd=50.0,  # Thumb abduction
    index_flex=60.0,  # Index flexion
    middle_flex=60.0,  # Middle flexion
    ring_flex=60.0,  # Ring flexion
    pinky_flex=60.0,  # Pinky flexion
    index_abd=30.0,  # Index abduction
    ring_abd=30.0,  # Ring abduction
    pinky_abd=30.0,  # Pinky abduction
    thumb_yaw=30.0,  # Thumb rotation
)
hand.torque.set_torques(torques)

Read Torque

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.torques.thumb_flex}")
    print(f"All torque values: {data.torques.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.torque.get_snapshot()
if data:
    print(f"Torque: {data.torques.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20lite import SensorSource, TorqueEvent

hand.start_polling({SensorSource.TORQUE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TorqueEvent(data=data):
                print(f"Torque: {data.torques.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20lite
from realhand.hand.l20lite import L20liteTorque

with L20lite(side="left", interface_name="can0") as hand:
    # Set torque
    hand.torque.set_torques([50.0] * 10)

    # Read current torque
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Current torque: {data.torques.to_list()}")

    # Fine-grained control with the data class
    torques = L20liteTorque(
        thumb_flex=70.0,
        thumb_abd=70.0,
        index_flex=50.0,
        middle_flex=50.0,
        ring_flex=50.0,
        pinky_flex=50.0,
        index_abd=40.0,
        ring_abd=40.0,
        pinky_abd=40.0,
        thumb_yaw=40.0,
    )
    hand.torque.set_torques(torques)

Temperature Reading

Use hand.temperature to read the temperature of the 10 L20Lite joint motors in °C.

Temperature fields

Read Temperature

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.temperature.get_blocking(timeout_ms=500)
    print(f"Thumb flexion temperature: {data.temperatures.thumb_flex}°C")
except TimeoutError:
    print("Read timed out")

Parameter

• timeout_ms: Timeout in milliseconds, default 100

Return value

• TemperatureData: Contains temperatures (L20liteTemperature) and timestamp

Exception

• TimeoutError: No response before timeout

Cached Read

Read the most recent cached temperature data without blocking.

data = hand.temperature.get_snapshot()
if data:
    print(f"Temperature: {data.temperatures.to_list()}")

Return value

• TemperatureData or None if no cached data is available

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20lite import SensorSource, TemperatureEvent

hand.start_polling({SensorSource.TEMPERATURE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TemperatureEvent(data=data):
                print(f"Temperature: {data.temperatures.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Read All Joint Temperatures

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    data = hand.temperature.get_blocking(timeout_ms=500)

    # Access by field
    print(f"Thumb flexion: {data.temperatures.thumb_flex}°C")
    print(f"Index flexion: {data.temperatures.index_flex}°C")

    # Convert to list
    temps = data.temperatures.to_list()
    print(f"All temperatures: {temps}")

    # Index access
    print(f"First joint motor: {data.temperatures[0]}°C")

Temperature Monitoring

from realhand import L20lite
from realhand.hand.l20lite import SensorSource, TemperatureEvent

with L20lite(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TEMPERATURE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TemperatureEvent(data=data):
                    for i, temp in enumerate(data.temperatures.to_list()):
                        if temp > 60.0:
                            print(f"Warning: joint motor {i} is overheating ({temp}°C)")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Force Sensors

The L20Lite dexterous hand is equipped with force sensors on 5 fingers (thumb, index, middle, ring, pinky). It supports both blocking and cached reads.

Overview

Use hand.force_sensor to access force sensor data:

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)

Data Structures

ForceSensorData - sensor data for one finger:

• values: A NumPy array of shape (12, 6) with dtype uint8
• timestamp: Unix timestamp

AllFingersData - data for all 5 fingers:

• thumb, index, middle, ring, pinky: the ForceSensorData for each finger

Read Data

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(data.thumb.values)  # Thumb data
    print(data.index.values)  # Index data
except TimeoutError:
    print("Read timed out")

Exceptions: TimeoutError (timeout), ValidationError (invalid parameter)

Cached Read

Get the most recently received data without blocking:

data = hand.force_sensor.get_snapshot()
if data:
    print(f"Thumb: {data.thumb.values[0]}")
    print(f"Index: {data.index.values[0]}")

Return value: AllFingersData or None if any finger is missing data

Read a Single Finger

Use get_finger() to access the force sensor manager for one finger:

# Get the thumb sensor
thumb_sensor = hand.force_sensor.get_finger("thumb")
thumb_data = thumb_sensor.get_blocking(timeout_ms=1000)
print(thumb_data.values.shape)  # (12, 6)

Available finger names: "thumb", "index", "middle", "ring", "pinky"

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20lite import SensorSource, ForceSensorEvent

hand.start_polling({SensorSource.FORCE_SENSOR: 0.1})

try:
    for event in hand.stream():
        match event:
            case ForceSensorEvent(data=data):
                print(data.thumb.values)
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Blocking Read for All Fingers

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(f"Thumb: {data.thumb.values.shape}")
    print(f"Index: {data.index.values.shape}")
    print(f"Middle: {data.middle.values.shape}")
    print(f"Ring: {data.ring.values.shape}")
    print(f"Pinky: {data.pinky.values.shape}")

Stream for a Fixed Duration

import time
from realhand import L20lite
from realhand.hand.l20lite import SensorSource, ForceSensorEvent

with L20lite(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FORCE_SENSOR: 0.05})
    start = time.time()

    try:
        for event in hand.stream():
            match event:
                case ForceSensorEvent(data=data):
                    print(f"Thumb: {data.thumb.values[0]}")
            if time.time() - start > 5:  # Collect for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Fault Handling

Fault detection for the L20Lite dexterous hand.

Overview

Use hand.fault to access fault-related functionality:

• Read fault status in blocking or cached mode

Fault Code Table

Read Faults

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.fault.get_blocking(timeout_ms=500)
except TimeoutError:
    print("Read timed out")

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Return value: FaultData, containing:

• faults: L20liteFault fault data
• timestamp: Timestamp

Exception:

• TimeoutError: No response before timeout

Cached Read

data = hand.fault.get_snapshot()
if data:
    print(f"Has fault: {data.faults.has_any_fault()}")

Returns the latest cached fault data, or None if no data is available.

Fault Data

L20liteFault fields

L20liteFault methods

# Check whether any fault exists
faults.has_any_fault()  # -> bool

# Convert to a list
faults.to_list()  # -> list[FaultCode]

# Index access
faults[0]  # thumb_flex

FaultCode methods

# Check whether a single joint motor has a fault
faults.thumb_flex.has_fault()  # -> bool

# Get fault names
faults.thumb_flex.get_fault_names()  # -> list[str]

Examples

Check Fault Status

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    # Read fault status
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        print("Fault detected:")
        if data.faults.thumb_flex.has_fault():
            print(f"  Thumb flexion: {data.faults.thumb_flex.get_fault_names()}")
        if data.faults.index_flex.has_fault():
            print(f"  Index flexion: {data.faults.index_flex.get_fault_names()}")
    else:
        print("No faults")

Iterate Through All Joint Faults

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        for i, code in enumerate(data.faults.to_list()):
            if code.has_fault():
                print(f"Joint {i} fault: {code.get_fault_names()}")

Version Information

Read version information for the L20Lite dexterous hand.

Overview

Use hand.version to access version-related functionality:

• Read complete device information, including serial number and PCB / firmware / mechanical versions

Read Device Information

hand.version.get_device_info() -> DeviceInfo

Returns a DeviceInfo object containing:

The Version object has major, minor, and patch fields, and its string format is V{major}.{minor}.{patch}.

Exception:

• TimeoutError: Request timed out

Example

Read Device Information

from realhand import L20lite

with L20lite(side="left", interface_name="can0") as hand:
    info = hand.version.get_device_info()
    print(f"Serial number: {info.serial_number}")
    print(f"PCB version: {info.pcb_version}")
    print(f"Firmware version: {info.firmware_version}")
    print(f"Mechanical version: {info.mechanical_version}")

L20 Dexterous Hand

Quick Start

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([50.0] * 16)

    # Read angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(data.angles)

Constructor parameters

Joint Definition

L20 has 16 degrees of freedom distributed across 5 fingers.

Functional Modules

Unified Streaming Reads

L20 provides a unified event stream interface. Use hand.stream() and hand.start_polling() to retrieve data from all sensors. Polling starts automatically at initialization using default intervals (angles at 60 Hz, force sensors at 30 Hz), so you do not need to call start_polling() manually.

from realhand import L20
from realhand.hand.l20 import SensorSource, AngleEvent, TemperatureEvent

with L20(side="left", interface_name="can0") as hand:
    # You can set multiple sensors and polling intervals (seconds)
    # Calling start_polling() again overrides the previous settings
    hand.start_polling({SensorSource.ANGLE: 0.05, SensorSource.TEMPERATURE: 1.0})

    for event in hand.stream():
        match event:
            case AngleEvent(data=ad):
                print(f"Angles: {ad.angles.to_list()}")
            case TemperatureEvent(data=td):
                print(f"Temperature: {td.temperatures.to_list()}")

    hand.stop_polling()
    hand.stop_stream()

start_polling parameter

Available SensorSource values and default rates

Snapshot

Get the latest cached data from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.speed)  # SpeedData | None
print(snap.torque)  # TorqueData | None
print(snap.temperature)  # TemperatureData | None
print(snap.fault)  # FaultData | None
print(snap.force_sensor)  # AllFingersData | None

Angle Control

Use hand.angle to control and read the 16 joint motor angles of the L20 dexterous hand.

• Angle range: 0-100
• Unit: Unitless, mapped to actual joint motor angles

Set Angles

from realhand import L20
from realhand.hand.l20 import L20Angle

# Using a list (16 joints)
hand.angle.set_angles([50.0] * 16)

# Using an L20Angle object
angles = L20Angle(
    thumb_abd=50.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=60.0,  # Thumb root
    thumb_tip=40.0,  # Thumb tip
    index_abd=50.0,  # Index abduction
    index_root1=60.0,  # Index root
    index_tip=40.0,  # Index tip
    middle_abd=50.0,  # Middle abduction
    middle_root1=60.0,  # Middle root
    middle_tip=40.0,  # Middle tip
    ring_abd=50.0,  # Ring abduction
    ring_root1=60.0,  # Ring root
    ring_tip=40.0,  # Ring tip
    pinky_abd=50.0,  # Pinky abduction
    pinky_root1=60.0,  # Pinky root
    pinky_tip=40.0,  # Pinky tip
)
hand.angle.set_angles(angles)

Read Angles

Blocking Read

from realhand import L20
from realhand.exceptions import TimeoutError

try:
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Thumb abduction: {data.angles.thumb_abd}")
    print(f"All angles: {data.angles.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.angle.get_snapshot()
if data:
    print(f"Angles: {data.angles.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

try:
    for event in hand.stream():
        match event:
            case AngleEvent(data=data):
                print(f"Angles: {data.angles.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([0.0] * 16)

    # Read current angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Current angles: {data.angles.to_list()}")

    # Incremental motion
    for i in range(0, 101, 10):
        hand.angle.set_angles([float(i)] * 16)

Speed Control

Use hand.speed to control and read the motion speed of each joint motor on the L20 dexterous hand.

• Speed range: 0-100
• Unit: Unitless

Set Speed

from realhand import L20
from realhand.hand.l20 import L20Speed

# Using a list (16 joints)
hand.speed.set_speeds([50.0] * 16)

# Using an L20Speed object
speed = L20Speed(
    thumb_abd=30.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=30.0,  # Thumb root
    thumb_tip=30.0,  # Thumb tip
    index_abd=80.0,  # Index abduction
    index_root1=80.0,  # Index root
    index_tip=80.0,  # Index tip
    middle_abd=80.0,  # Middle abduction
    middle_root1=80.0,  # Middle root
    middle_tip=80.0,  # Middle tip
    ring_abd=80.0,  # Ring abduction
    ring_root1=80.0,  # Ring root
    ring_tip=80.0,  # Ring tip
    pinky_abd=80.0,  # Pinky abduction
    pinky_root1=80.0,  # Pinky root
    pinky_tip=80.0,  # Pinky tip
)
hand.speed.set_speeds(speed)

Read Speed

Blocking Read

from realhand import L20
from realhand.exceptions import TimeoutError

try:
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Thumb abduction speed: {data.speeds.thumb_abd}")
    print(f"All speeds: {data.speeds.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.speed.get_snapshot()
if data:
    print(f"Speed: {data.speeds.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, SpeedEvent

hand.start_polling({SensorSource.SPEED: 0.1})

try:
    for event in hand.stream():
        match event:
            case SpeedEvent(data=data):
                print(f"Speed: {data.speeds.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20
from realhand.hand.l20 import L20Speed

with L20(side="left", interface_name="can0") as hand:
    # Set speed
    speed = L20Speed(
        thumb_abd=30.0,
        thumb_yaw=30.0,
        thumb_root1=30.0,
        thumb_tip=30.0,
        index_abd=80.0,
        index_root1=80.0,
        index_tip=80.0,
        middle_abd=80.0,
        middle_root1=80.0,
        middle_tip=80.0,
        ring_abd=80.0,
        ring_root1=80.0,
        ring_tip=80.0,
        pinky_abd=80.0,
        pinky_root1=80.0,
        pinky_tip=80.0,
    )
    hand.speed.set_speeds(speed)

    # Read current speed
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Current speed: {data.speeds.to_list()}")

Torque Control

Use hand.torque to control and read the torque of the 16 joint motors on the L20 dexterous hand.

• Torque range: 0-100
• Unit: Unitless percentage

Set Torque

from realhand import L20
from realhand.hand.l20 import L20Torque

# Using a list (16 joints)
hand.torque.set_torques([50.0] * 16)

# Using an L20Torque object
torques = L20Torque(
    thumb_abd=50.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=60.0,  # Thumb root
    thumb_tip=40.0,  # Thumb tip
    index_abd=50.0,  # Index abduction
    index_root1=60.0,  # Index root
    index_tip=40.0,  # Index tip
    middle_abd=50.0,  # Middle abduction
    middle_root1=60.0,  # Middle root
    middle_tip=40.0,  # Middle tip
    ring_abd=50.0,  # Ring abduction
    ring_root1=60.0,  # Ring root
    ring_tip=40.0,  # Ring tip
    pinky_abd=50.0,  # Pinky abduction
    pinky_root1=60.0,  # Pinky root
    pinky_tip=40.0,  # Pinky tip
)
hand.torque.set_torques(torques)

Read Torque

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Thumb abduction: {data.torques.thumb_abd}")
    print(f"All torque values: {data.torques.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.torque.get_snapshot()
if data:
    print(f"Torque: {data.torques.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, TorqueEvent

hand.start_polling({SensorSource.TORQUE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TorqueEvent(data=data):
                print(f"Torque: {data.torques.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    # Set torque
    hand.torque.set_torques([50.0] * 16)

    # Read current torque
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Current torque: {data.torques.to_list()}")

    # Set different torque values for each finger
    hand.torque.set_torques(
        [
            80.0,
            80.0,
            80.0,
            80.0,  # Thumb
            60.0,
            60.0,
            60.0,  # Index
            60.0,
            60.0,
            60.0,  # Middle
            60.0,
            60.0,
            60.0,  # Ring
            60.0,
            60.0,
            60.0,  # Pinky
        ]
    )

Temperature Reading

Use hand.temperature to read the temperature of the 16 L20 joint motors in °C.

Temperature fields

Read Temperature

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.temperature.get_blocking(timeout_ms=500)
    print(f"Thumb abduction temperature: {data.temperatures.thumb_abd}°C")
except TimeoutError:
    print("Read timed out")

Parameter

• timeout_ms: Timeout in milliseconds, default 100

Return value

• TemperatureData: Contains temperatures (L20Temperature) and timestamp

Exception

• TimeoutError: No response before timeout

Cached Read

Read the most recent cached temperature data without blocking.

data = hand.temperature.get_snapshot()
if data:
    print(f"Temperature: {data.temperatures.to_list()}")

Return value

• TemperatureData or None if no cached data is available

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, TemperatureEvent

hand.start_polling({SensorSource.TEMPERATURE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TemperatureEvent(data=data):
                print(f"Temperature: {data.temperatures.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Read All Joint Temperatures

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    data = hand.temperature.get_blocking(timeout_ms=500)

    # Access by field
    print(f"Thumb abduction: {data.temperatures.thumb_abd}°C")
    print(f"Index abduction: {data.temperatures.index_abd}°C")

    # Convert to list
    temps = data.temperatures.to_list()
    print(f"All temperatures: {temps}")

    # Index access
    print(f"First joint motor: {data.temperatures[0]}°C")

Temperature Monitoring

from realhand import L20
from realhand.hand.l20 import SensorSource, TemperatureEvent

with L20(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TEMPERATURE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TemperatureEvent(data=data):
                    for i, temp in enumerate(data.temperatures.to_list()):
                        if temp > 60.0:
                            print(f"Warning: joint motor {i} is overheating ({temp}°C)")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Force Sensors

The L20 dexterous hand is equipped with force sensors on 5 fingers (thumb, index, middle, ring, pinky). It supports both blocking and cached reads.

Overview

Use hand.force_sensor to access force sensor data:

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking()

Data Structures

ForceSensorData - sensor data for one finger:

• values: A NumPy array of shape (12, 6) with dtype uint8
• timestamp: Unix timestamp

AllFingersData - data for all 5 fingers:

• thumb, index, middle, ring, pinky: the ForceSensorData for each finger

Read Data

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(data.thumb.values)  # Thumb data
    print(data.index.values)  # Index data
except TimeoutError:
    print("Read timed out")

Exceptions: TimeoutError (timeout), ValidationError (invalid parameter)

Cached Read

Get the most recently received data without blocking:

data = hand.force_sensor.get_snapshot()
if data:
    print(f"Thumb: {data.thumb.values[0]}")
    print(f"Index: {data.index.values[0]}")

Return value: AllFingersData or None if any finger is missing data

Read a Single Finger

Use get_finger() to access the sensor manager for one finger, with independent blocking and cached reads:

# Get the thumb force sensor manager
thumb_sensor = hand.force_sensor.get_finger("thumb")

# Blocking read for thumb data
thumb_data = thumb_sensor.get_blocking(timeout_ms=1000)
print(f"Thumb: {thumb_data.values.shape}")

# Cached read for thumb data
thumb_data = thumb_sensor.get_snapshot()
if thumb_data:
    print(f"Thumb: {thumb_data.values[0]}")

Available finger names: "thumb", "index", "middle", "ring", "pinky"

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, ForceSensorEvent

hand.start_polling({SensorSource.FORCE_SENSOR: 0.1})

try:
    for event in hand.stream():
        match event:
            case ForceSensorEvent(data=data):
                print(data.thumb.values)
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Blocking Read for All Fingers

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(f"Thumb: {data.thumb.values.shape}")
    print(f"Index: {data.index.values.shape}")
    print(f"Middle: {data.middle.values.shape}")
    print(f"Ring: {data.ring.values.shape}")
    print(f"Pinky: {data.pinky.values.shape}")

Stream for a Fixed Duration

import time
from realhand import L20
from realhand.hand.l20 import SensorSource, ForceSensorEvent

with L20(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FORCE_SENSOR: 0.05})
    start = time.time()

    try:
        for event in hand.stream():
            match event:
                case ForceSensorEvent(data=data):
                    print(f"Thumb: {data.thumb.values[0]}")
            if time.time() - start > 5:  # Collect for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Fault Handling

Fault detection and clearing for the L20 dexterous hand.

Overview

Use hand.fault to access fault-related functionality:

• Read fault status in blocking or cached mode
• Clear faults on all joints

Fault Code Table

L20 represents fault states with bit flags. Each joint motor can report multiple faults at the same time.

Read Faults

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.fault.get_blocking(timeout_ms=500)
except TimeoutError:
    print("Read timed out")

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Return value: FaultData, containing:

• faults: L20Fault fault data
• timestamp: Timestamp

Exception:

• TimeoutError: No response before timeout

Cached Read

data = hand.fault.get_snapshot()
if data:
    print(f"Has fault: {data.faults.has_any_fault()}")

Returns the latest cached fault data, or None if no data is available.

Clear Faults

hand.fault.clear_faults()

Sends a fire-and-forget command to clear faults on all joints, without waiting for a response.

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l20 import SensorSource, FaultEvent

hand.start_polling({SensorSource.FAULT: 0.2})

try:
    for event in hand.stream():
        match event:
            case FaultEvent(data=data):
                if data.faults.has_any_fault():
                    for code in data.faults.to_list():
                        if code.has_fault():
                            print(code.get_fault_names())
finally:
    hand.stop_polling()
    hand.stop_stream()

Data Class Reference

L20Fault fields

L20Fault methods

# Check whether any fault exists
faults.has_any_fault()  # -> bool

# Convert to a list
faults.to_list()  # -> list[L20FaultCode]

# Index access
faults[0]  # thumb_abd

L20FaultCode methods

# Check whether a single joint motor has a fault
faults.thumb_abd.has_fault()  # -> bool

# Get the list of fault names
faults.thumb_abd.get_fault_names()  # -> list[str]

Examples

Check Fault Status

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    # Read fault status
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        print("Fault detected:")
        if data.faults.thumb_abd.has_fault():
            print(f"  Thumb abduction: {data.faults.thumb_abd.get_fault_names()}")
        if data.faults.index_abd.has_fault():
            print(f"  Index abduction: {data.faults.index_abd.get_fault_names()}")
    else:
        print("No faults")

    # Clear all faults
    hand.fault.clear_faults()

Continuous Monitoring

from realhand import L20
from realhand.hand.l20 import SensorSource, FaultEvent

with L20(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FAULT: 0.2})

    try:
        for event in hand.stream():
            match event:
                case FaultEvent(data=data):
                    if data.faults.has_any_fault():
                        for i, code in enumerate(data.faults.to_list()):
                            if code.has_fault():
                                print(f"Joint {i} fault: {code.get_fault_names()}")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Version Information

Read version information for the L20 dexterous hand.

Overview

Use hand.version to access version-related functionality:

• Read complete device information, including serial number and PCB / firmware / mechanical versions

Read Device Information

hand.version.get_device_info() -> DeviceInfo

Returns a DeviceInfo object containing:

The Version object has major, minor, and patch fields, and its string format is V{major}.{minor}.{patch}.

Exception:

• TimeoutError: Request timed out

Example

Read Device Information

from realhand import L20

with L20(side="left", interface_name="can0") as hand:
    info = hand.version.get_device_info()
    print(f"Serial number: {info.serial_number}")
    print(f"PCB version: {info.pcb_version}")
    print(f"Firmware version: {info.firmware_version}")
    print(f"Mechanical version: {info.mechanical_version}")

L25 Dexterous Hand

Quick Start

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([50.0] * 16)

    # Read angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(data.angles)

Constructor parameters

Joint Definition

L25 has 16 degrees of freedom distributed across 5 fingers.

Functional Modules

Unified Streaming Reads

L25 provides a unified event stream interface. Use hand.stream() and hand.start_polling() to retrieve data from all sensors. Polling starts automatically at initialization using default intervals (angles at 60 Hz, force sensors at 30 Hz), so you do not need to call start_polling() manually.

from realhand import L25
from realhand.hand.l25 import SensorSource, AngleEvent, TemperatureEvent

with L25(side="left", interface_name="can0") as hand:
    # You can set multiple sensors and polling intervals (seconds)
    # Calling start_polling() again overrides the previous settings
    hand.start_polling({SensorSource.ANGLE: 0.05, SensorSource.TEMPERATURE: 1.0})

    for event in hand.stream():
        match event:
            case AngleEvent(data=ad):
                print(f"Angles: {ad.angles.to_list()}")
            case TemperatureEvent(data=td):
                print(f"Temperature: {td.temperatures.to_list()}")

    hand.stop_polling()
    hand.stop_stream()

start_polling parameter

Available SensorSource values and default rates

Snapshot

Get the latest cached data from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.speed)  # SpeedData | None
print(snap.torque)  # TorqueData | None
print(snap.temperature)  # TemperatureData | None
print(snap.fault)  # FaultData | None
print(snap.force_sensor)  # AllFingersData | None

Angle Control

Use hand.angle to control and read the 16 joint motor angles of the L25 dexterous hand.

• Angle range: 0-100
• Unit: Unitless, mapped to actual joint motor angles

Set Angles

from realhand import L25
from realhand.hand.l25 import L25Angle

# Using a list (16 joints)
hand.angle.set_angles([50.0] * 16)

# Using an L25Angle object
angles = L25Angle(
    thumb_abd=50.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=60.0,  # Thumb root
    thumb_tip=40.0,  # Thumb tip
    index_abd=50.0,  # Index abduction
    index_root1=60.0,  # Index root
    index_tip=40.0,  # Index tip
    middle_abd=50.0,  # Middle abduction
    middle_root1=60.0,  # Middle root
    middle_tip=40.0,  # Middle tip
    ring_abd=50.0,  # Ring abduction
    ring_root1=60.0,  # Ring root
    ring_tip=40.0,  # Ring tip
    pinky_abd=50.0,  # Pinky abduction
    pinky_root1=60.0,  # Pinky root
    pinky_tip=40.0,  # Pinky tip
)
hand.angle.set_angles(angles)

Read Angles

Blocking Read

from realhand import L25
from realhand.exceptions import TimeoutError

try:
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Thumb abduction: {data.angles.thumb_abd}")
    print(f"All angles: {data.angles.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.angle.get_snapshot()
if data:
    print(f"Angles: {data.angles.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

try:
    for event in hand.stream():
        match event:
            case AngleEvent(data=data):
                print(f"Angles: {data.angles.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([0.0] * 16)

    # Read current angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Current angles: {data.angles.to_list()}")

    # Incremental motion
    for i in range(0, 101, 10):
        hand.angle.set_angles([float(i)] * 16)

Speed Control

Use hand.speed to control and read the motion speed of each joint motor on the L25 dexterous hand.

• Speed range: 0-100
• Unit: Unitless

Set Speed

from realhand import L25
from realhand.hand.l25 import L25Speed

# Using a list (16 joints)
hand.speed.set_speeds([50.0] * 16)

# Using an L25Speed object
speed = L25Speed(
    thumb_abd=30.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=30.0,  # Thumb root
    thumb_tip=30.0,  # Thumb tip
    index_abd=80.0,  # Index abduction
    index_root1=80.0,  # Index root
    index_tip=80.0,  # Index tip
    middle_abd=80.0,  # Middle abduction
    middle_root1=80.0,  # Middle root
    middle_tip=80.0,  # Middle tip
    ring_abd=80.0,  # Ring abduction
    ring_root1=80.0,  # Ring root
    ring_tip=80.0,  # Ring tip
    pinky_abd=80.0,  # Pinky abduction
    pinky_root1=80.0,  # Pinky root
    pinky_tip=80.0,  # Pinky tip
)
hand.speed.set_speeds(speed)

Read Speed

Blocking Read

from realhand import L25
from realhand.exceptions import TimeoutError

try:
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Thumb abduction speed: {data.speeds.thumb_abd}")
    print(f"All speeds: {data.speeds.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.speed.get_snapshot()
if data:
    print(f"Speed: {data.speeds.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, SpeedEvent

hand.start_polling({SensorSource.SPEED: 0.1})

try:
    for event in hand.stream():
        match event:
            case SpeedEvent(data=data):
                print(f"Speed: {data.speeds.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L25
from realhand.hand.l25 import L25Speed

with L25(side="left", interface_name="can0") as hand:
    # Set speed
    speed = L25Speed(
        thumb_abd=30.0,
        thumb_yaw=30.0,
        thumb_root1=30.0,
        thumb_tip=30.0,
        index_abd=80.0,
        index_root1=80.0,
        index_tip=80.0,
        middle_abd=80.0,
        middle_root1=80.0,
        middle_tip=80.0,
        ring_abd=80.0,
        ring_root1=80.0,
        ring_tip=80.0,
        pinky_abd=80.0,
        pinky_root1=80.0,
        pinky_tip=80.0,
    )
    hand.speed.set_speeds(speed)

    # Read current speed
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Current speed: {data.speeds.to_list()}")

Torque Control

Use hand.torque to control and read the torque of the 16 joint motors on the L25 dexterous hand.

• Torque range: 0-100
• Unit: Unitless percentage

Set Torque

from realhand import L25
from realhand.hand.l25 import L25Torque

# Using a list (16 joints)
hand.torque.set_torques([50.0] * 16)

# Using an L25Torque object
torques = L25Torque(
    thumb_abd=50.0,  # Thumb abduction
    thumb_yaw=30.0,  # Thumb rotation
    thumb_root1=60.0,  # Thumb root
    thumb_tip=40.0,  # Thumb tip
    index_abd=50.0,  # Index abduction
    index_root1=60.0,  # Index root
    index_tip=40.0,  # Index tip
    middle_abd=50.0,  # Middle abduction
    middle_root1=60.0,  # Middle root
    middle_tip=40.0,  # Middle tip
    ring_abd=50.0,  # Ring abduction
    ring_root1=60.0,  # Ring root
    ring_tip=40.0,  # Ring tip
    pinky_abd=50.0,  # Pinky abduction
    pinky_root1=60.0,  # Pinky root
    pinky_tip=40.0,  # Pinky tip
)
hand.torque.set_torques(torques)

Read Torque

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Thumb abduction: {data.torques.thumb_abd}")
    print(f"All torque values: {data.torques.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.torque.get_snapshot()
if data:
    print(f"Torque: {data.torques.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, TorqueEvent

hand.start_polling({SensorSource.TORQUE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TorqueEvent(data=data):
                print(f"Torque: {data.torques.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Complete Example

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    # Set torque
    hand.torque.set_torques([50.0] * 16)

    # Read current torque
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Current torque: {data.torques.to_list()}")

    # Set different torque values for each finger
    hand.torque.set_torques(
        [
            80.0,
            80.0,
            80.0,
            80.0,  # Thumb
            60.0,
            60.0,
            60.0,  # Index
            60.0,
            60.0,
            60.0,  # Middle
            60.0,
            60.0,
            60.0,  # Ring
            60.0,
            60.0,
            60.0,  # Pinky
        ]
    )

Temperature Reading

Use hand.temperature to read the temperature of the 16 L25 joint motors in °C.

Temperature fields

Read Temperature

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.temperature.get_blocking(timeout_ms=500)
    print(f"Thumb abduction temperature: {data.temperatures.thumb_abd}°C")
except TimeoutError:
    print("Read timed out")

Parameter

• timeout_ms: Timeout in milliseconds, default 100

Return value

• TemperatureData: Contains temperatures (L25Temperature) and timestamp

Exception

• TimeoutError: No response before timeout

Cached Read

Read the most recent cached temperature data without blocking.

data = hand.temperature.get_snapshot()
if data:
    print(f"Temperature: {data.temperatures.to_list()}")

Return value

• TemperatureData or None if no cached data is available

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, TemperatureEvent

hand.start_polling({SensorSource.TEMPERATURE: 0.1})

try:
    for event in hand.stream():
        match event:
            case TemperatureEvent(data=data):
                print(f"Temperature: {data.temperatures.to_list()}")
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Read All Joint Temperatures

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    data = hand.temperature.get_blocking(timeout_ms=500)

    # Access by field
    print(f"Thumb abduction: {data.temperatures.thumb_abd}°C")
    print(f"Index abduction: {data.temperatures.index_abd}°C")

    # Convert to list
    temps = data.temperatures.to_list()
    print(f"All temperatures: {temps}")

    # Index access
    print(f"First joint motor: {data.temperatures[0]}°C")

Temperature Monitoring

from realhand import L25
from realhand.hand.l25 import SensorSource, TemperatureEvent

with L25(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TEMPERATURE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TemperatureEvent(data=data):
                    for i, temp in enumerate(data.temperatures.to_list()):
                        if temp > 60.0:
                            print(f"Warning: joint motor {i} is overheating ({temp}°C)")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Force Sensors

The L25 dexterous hand is equipped with force sensors on 5 fingers (thumb, index, middle, ring, pinky). It supports both blocking and cached reads.

Overview

Use hand.force_sensor to access force sensor data:

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking()

Data Structures

ForceSensorData - sensor data for one finger:

• values: A NumPy array of shape (12, 6) with dtype uint8
• timestamp: Unix timestamp

AllFingersData - data for all 5 fingers:

• thumb, index, middle, ring, pinky: the ForceSensorData for each finger

Read Data

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(data.thumb.values)  # Thumb data
    print(data.index.values)  # Index data
except TimeoutError:
    print("Read timed out")

Exceptions: TimeoutError (timeout), ValidationError (invalid parameter)

Cached Read

Get the most recently received data without blocking:

data = hand.force_sensor.get_snapshot()
if data:
    print(f"Thumb: {data.thumb.values[0]}")
    print(f"Index: {data.index.values[0]}")

Return value: AllFingersData or None if any finger is missing data

Read a Single Finger

Use get_finger() to access the sensor manager for one finger, with independent blocking and cached reads:

# Get the thumb force sensor manager
thumb_sensor = hand.force_sensor.get_finger("thumb")

# Blocking read for thumb data
thumb_data = thumb_sensor.get_blocking(timeout_ms=1000)
print(f"Thumb: {thumb_data.values.shape}")

# Cached read for thumb data
thumb_data = thumb_sensor.get_snapshot()
if thumb_data:
    print(f"Thumb: {thumb_data.values[0]}")

Available finger names: "thumb", "index", "middle", "ring", "pinky"

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, ForceSensorEvent

hand.start_polling({SensorSource.FORCE_SENSOR: 0.1})

try:
    for event in hand.stream():
        match event:
            case ForceSensorEvent(data=data):
                print(data.thumb.values)
finally:
    hand.stop_polling()
    hand.stop_stream()

Examples

Blocking Read for All Fingers

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(f"Thumb: {data.thumb.values.shape}")
    print(f"Index: {data.index.values.shape}")
    print(f"Middle: {data.middle.values.shape}")
    print(f"Ring: {data.ring.values.shape}")
    print(f"Pinky: {data.pinky.values.shape}")

Stream for a Fixed Duration

import time
from realhand import L25
from realhand.hand.l25 import SensorSource, ForceSensorEvent

with L25(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FORCE_SENSOR: 0.05})
    start = time.time()

    try:
        for event in hand.stream():
            match event:
                case ForceSensorEvent(data=data):
                    print(f"Thumb: {data.thumb.values[0]}")
            if time.time() - start > 5:  # Collect for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Fault Handling

Fault detection and clearing for the L25 dexterous hand.

Overview

Use hand.fault to access fault-related functionality:

• Read fault status in blocking or cached mode
• Clear faults on all joints

Fault Code Table

L25 represents fault states with bit flags. Each joint motor can report multiple faults at the same time.

Read Faults

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.fault.get_blocking(timeout_ms=500)
except TimeoutError:
    print("Read timed out")

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Return value: FaultData, containing:

• faults: L25Fault fault data
• timestamp: Timestamp

Exception:

• TimeoutError: No response before timeout

Cached Read

data = hand.fault.get_snapshot()
if data:
    print(f"Has fault: {data.faults.has_any_fault()}")

Returns the latest cached fault data, or None if no data is available.

Clear Faults

hand.fault.clear_faults()

Sends a fire-and-forget command to clear faults on all joints, without waiting for a response.

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.l25 import SensorSource, FaultEvent

hand.start_polling({SensorSource.FAULT: 0.2})

try:
    for event in hand.stream():
        match event:
            case FaultEvent(data=data):
                if data.faults.has_any_fault():
                    for code in data.faults.to_list():
                        if code.has_fault():
                            print(code.get_fault_names())
finally:
    hand.stop_polling()
    hand.stop_stream()

Data Class Reference

L25Fault fields

L25Fault methods

# Check whether any fault exists
faults.has_any_fault()  # -> bool

# Convert to a list
faults.to_list()  # -> list[L25FaultCode]

# Index access
faults[0]  # thumb_abd

L25FaultCode methods

# Check whether a single joint motor has a fault
faults.thumb_abd.has_fault()  # -> bool

# Get the list of fault names
faults.thumb_abd.get_fault_names()  # -> list[str]

Examples

Check Fault Status

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    # Read fault status
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        print("Fault detected:")
        if data.faults.thumb_abd.has_fault():
            print(f"  Thumb abduction: {data.faults.thumb_abd.get_fault_names()}")
        if data.faults.index_abd.has_fault():
            print(f"  Index abduction: {data.faults.index_abd.get_fault_names()}")
    else:
        print("No faults")

    # Clear all faults
    hand.fault.clear_faults()

Continuous Monitoring

from realhand import L25
from realhand.hand.l25 import SensorSource, FaultEvent

with L25(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FAULT: 0.2})

    try:
        for event in hand.stream():
            match event:
                case FaultEvent(data=data):
                    if data.faults.has_any_fault():
                        for i, code in enumerate(data.faults.to_list()):
                            if code.has_fault():
                                print(f"Joint {i} fault: {code.get_fault_names()}")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Version Information

Read version information for the L25 dexterous hand.

Overview

Use hand.version to access version-related functionality:

• Read complete device information, including serial number and PCB / firmware / mechanical versions

Read Device Information

hand.version.get_device_info() -> DeviceInfo

Returns a DeviceInfo object containing:

The Version object has major, minor, and patch fields, and its string format is V{major}.{minor}.{patch}.

Exception:

• TimeoutError: Request timed out

Example

Read Device Information

from realhand import L25

with L25(side="left", interface_name="can0") as hand:
    info = hand.version.get_device_info()
    print(f"Serial number: {info.serial_number}")
    print(f"PCB version: {info.pcb_version}")
    print(f"Firmware version: {info.firmware_version}")
    print(f"Mechanical version: {info.mechanical_version}")

O6 Dexterous Hand

Quick Start

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles((10, 20, 30, 40, 50, 60))

    # Read angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(data.angles)

Constructor parameters

Joint Definition

Functional Modules

Unified Streaming Reads

O6 provides a unified event stream interface. Use hand.stream() and hand.start_polling() to retrieve data from all sensors. Polling starts automatically at initialization using default intervals (angles at 60 Hz, force sensors at 30 Hz), so you do not need to call start_polling() manually.

from realhand import O6
from realhand.hand.o6 import SensorSource, AngleEvent, TemperatureEvent

with O6(side="left", interface_name="can0") as hand:
    # You can set multiple sensors and polling intervals (seconds)
    # Calling start_polling() again overrides the previous settings
    hand.start_polling({SensorSource.ANGLE: 0.05, SensorSource.TEMPERATURE: 1.0})

    for event in hand.stream():
        match event:
            case AngleEvent(data=ad):
                print(f"Angles: {ad.angles.to_list()}")
            case TemperatureEvent(data=td):
                print(f"Temperature: {td.temperatures.to_list()}")

    hand.stop_polling()
    hand.stop_stream()

Available SensorSource values and default rates

Snapshot

Get the latest cached data from all sensors:

snap = hand.get_snapshot()
print(snap.angle)  # AngleData | None
print(snap.temperature)  # TemperatureData | None

Angle Control

Use hand.angle to control and read the 6 joint motor angles of the O6 dexterous hand.

• Angle range: 0-100
• Unit: Unitless, mapped to actual joint motor angles

Set Angles

from realhand import O6
from realhand.hand.o6 import O6Angle

# Using a list
hand.angle.set_angles([50.0, 30.0, 60.0, 60.0, 60.0, 60.0])

# Using an O6Angle object
angles = O6Angle(
    thumb_flex=50.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index=60.0,  # Index finger
    middle=60.0,  # Middle finger
    ring=60.0,  # Ring finger
    pinky=60.0,  # Pinky
)
hand.angle.set_angles(angles)

Read Angles

Blocking Read

from realhand import O6
from realhand.exceptions import TimeoutError

try:
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.angles.thumb_flex}")
    print(f"All angles: {data.angles.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.angle.get_snapshot()
if data:
    print(f"Angles: {data.angles.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, AngleEvent

hand.start_polling({SensorSource.ANGLE: 0.1})

for event in hand.stream():
    match event:
        case AngleEvent(data=data):
            print(f"Angles: {data.angles.to_list()}")

hand.stop_polling()
hand.stop_stream()

Complete Example

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    # Set angles
    hand.angle.set_angles([0.0, 0.0, 0.0, 0.0, 0.0, 0.0])

    # Read current angles
    data = hand.angle.get_blocking(timeout_ms=500)
    print(f"Current angles: {data.angles.to_list()}")

    # Incremental motion
    for i in range(0, 101, 10):
        hand.angle.set_angles([float(i)] * 6)

Speed Control

Use hand.speed to control and read the motion speed of each joint motor on the O6 dexterous hand.

• Speed range: 0-100
• Maximum RPM: 186.66 RPM at value 100

Set Speed

from realhand import O6
from realhand.hand.o6 import O6Speed

# Using a list
hand.speed.set_speeds([50.0, 50.0, 50.0, 50.0, 50.0, 50.0])

# Using an O6Speed object
speed = O6Speed(
    thumb_flex=30.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index=80.0,  # Index finger
    middle=80.0,  # Middle finger
    ring=80.0,  # Ring finger
    pinky=80.0,  # Pinky
)
hand.speed.set_speeds(speed)

Read Speed

Blocking Read

from realhand import O6
from realhand.exceptions import TimeoutError

try:
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Thumb flexion speed: {data.speeds.thumb_flex}")
    print(f"All speeds: {data.speeds.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.speed.get_snapshot()
if data:
    print(f"Speed: {data.speeds.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, SpeedEvent

hand.start_polling({SensorSource.SPEED: 0.1})

for event in hand.stream():
    match event:
        case SpeedEvent(data=data):
            print(f"Speed: {data.speeds.to_list()}")

hand.stop_polling()
hand.stop_stream()

RPM Conversion

O6Speed supports conversion to and from RPM.

Convert to RPM

from realhand.hand.o6 import O6Speed

speed = O6Speed(50.0, 50.0, 50.0, 50.0, 50.0, 50.0)
rpm_values = speed.to_rpm()
print(rpm_values)  # [93.33, 93.33, 93.33, 93.33, 93.33, 93.33]

Create from RPM

from realhand.hand.o6 import O6Speed

# Set all joint motors to 90 RPM
speed = O6Speed.from_rpm([90.0, 90.0, 90.0, 90.0, 90.0, 90.0])
hand.speed.set_speeds(speed)

# Thumb slow, other fingers fast
speed = O6Speed.from_rpm([60.0, 60.0, 120.0, 120.0, 120.0, 120.0])
hand.speed.set_speeds(speed)

Complete Example

from realhand import O6
from realhand.hand.o6 import O6Speed

with O6(side="left", interface_name="can0") as hand:
    # Set speed using RPM
    speed = O6Speed.from_rpm([90.0, 90.0, 120.0, 120.0, 120.0, 120.0])
    hand.speed.set_speeds(speed)

    # Read current speed
    data = hand.speed.get_blocking(timeout_ms=500)
    print(f"Current speed: {data.speeds.to_list()}")
    print(f"RPM: {data.speeds.to_rpm()}")

Acceleration Control

Use hand.acceleration to control and read the acceleration of the 6 joint motors on the O6 dexterous hand.

• Acceleration range: 0-100
• Maximum acceleration: 2209.8 deg/s² at value 100

Set Acceleration

from realhand import O6
from realhand.hand.o6 import O6Acceleration

# Using a list
hand.acceleration.set_accelerations([80.0, 80.0, 80.0, 80.0, 80.0, 80.0])

# Using an O6Acceleration object
accel = O6Acceleration(
    thumb_flex=80.0,  # Thumb flexion
    thumb_abd=80.0,  # Thumb abduction
    index=80.0,  # Index finger
    middle=80.0,  # Middle finger
    ring=80.0,  # Ring finger
    pinky=80.0,  # Pinky
)
hand.acceleration.set_accelerations(accel)

Read Acceleration

Blocking Read

from realhand import O6
from realhand.exceptions import TimeoutError

try:
    data = hand.acceleration.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.accelerations.thumb_flex}")
    print(f"All accelerations: {data.accelerations.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.acceleration.get_snapshot()
if data:
    print(f"Acceleration: {data.accelerations.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, AccelerationEvent

hand.start_polling({SensorSource.ACCELERATION: 0.1})

for event in hand.stream():
    match event:
        case AccelerationEvent(data=data):
            print(f"Acceleration: {data.accelerations.to_list()}")

hand.stop_polling()
hand.stop_stream()

deg/s² Conversion

O6Acceleration supports conversion to and from the physical unit deg/s².

Convert to deg/s²

from realhand.hand.o6 import O6Acceleration

accel = O6Acceleration(50.0, 50.0, 50.0, 50.0, 50.0, 50.0)
deg_s2_values = accel.to_deg_per_sec2()
print(deg_s2_values)  # [1104.9, 1104.9, 1104.9, 1104.9, 1104.9, 1104.9]

Create from deg/s²

from realhand.hand.o6 import O6Acceleration

# Set all joint motor accelerations to 1000 deg/s²
accel = O6Acceleration.from_deg_per_sec2([1000.0] * 6)

# Set different accelerations
accel = O6Acceleration.from_deg_per_sec2(
    [
        1500.0,  # Thumb flexion
        1200.0,  # Thumb abduction
        1800.0,  # Index finger
        1800.0,  # Middle finger
        1800.0,  # Ring finger
        1800.0,  # Pinky
    ]
)

Complete Example

from realhand import O6
from realhand.hand.o6 import O6Acceleration

with O6(side="left", interface_name="can0") as hand:
    # Set a lower acceleration for smoother motion
    hand.acceleration.set_accelerations([30.0] * 6)

    # Set acceleration using deg/s²
    accel = O6Acceleration.from_deg_per_sec2([1000.0] * 6)
    hand.acceleration.set_accelerations(accel)

    # Read current acceleration
    data = hand.acceleration.get_blocking(timeout_ms=500)
    print(f"Current acceleration: {data.accelerations.to_list()}")
    print(f"In deg/s²: {data.accelerations.to_deg_per_sec2()}")

Torque Control

Use hand.torque to control and read the torque of the 6 joint motors on the O6 dexterous hand.

• Torque range: 0-100 (unitless percentage)
• Maximum current: 1657.5 mA at value 100

Set Torque

from realhand import O6
from realhand.hand.o6 import O6Torque

# Using a list
hand.torque.set_torques([50.0, 30.0, 60.0, 60.0, 60.0, 60.0])

# Using an O6Torque object
torques = O6Torque(
    thumb_flex=50.0,  # Thumb flexion
    thumb_abd=30.0,  # Thumb abduction
    index=60.0,  # Index finger
    middle=60.0,  # Middle finger
    ring=60.0,  # Ring finger
    pinky=60.0,  # Pinky
)
hand.torque.set_torques(torques)

# Using mA values
torques = O6Torque.from_milliamps([800.0, 800.0, 1000.0, 1000.0, 1000.0, 1000.0])
hand.torque.set_torques(torques)

Read Torque

Blocking Read

from realhand.exceptions import TimeoutError

try:
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Thumb flexion: {data.torques.thumb_flex}")
    print(f"All torque values: {data.torques.to_list()}")
except TimeoutError:
    print("Read timed out")

Cached Read

data = hand.torque.get_snapshot()
if data:
    print(f"Torque: {data.torques.to_list()}")
    print(f"Timestamp: {data.timestamp}")

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, TorqueEvent

hand.start_polling({SensorSource.TORQUE: 0.1})

for event in hand.stream():
    match event:
        case TorqueEvent(data=data):
            print(f"Torque: {data.torques.to_list()}")

hand.stop_polling()
hand.stop_stream()

mA Conversion

O6 supports conversion between torque values and current values in mA.

Create from mA

from realhand.hand.o6 import O6Torque

# Create from mA values (range 0-1657.5 mA)
torques = O6Torque.from_milliamps([800.0, 800.0, 1000.0, 1000.0, 1200.0, 1200.0])
print(f"Normalized values: {torques.to_list()}")  # Converted to the 0-100 range

Convert to mA

torques = O6Torque(50.0, 50.0, 50.0, 50.0, 50.0, 50.0)
ma_values = torques.to_milliamps()
print(f"mA values: {ma_values}")  # [828.75, 828.75, ...]

Complete Example

from realhand import O6
from realhand.hand.o6 import O6Torque

with O6(side="left", interface_name="can0") as hand:
    # Set torque
    hand.torque.set_torques([50.0, 50.0, 50.0, 50.0, 50.0, 50.0])

    # Read current torque
    data = hand.torque.get_blocking(timeout_ms=500)
    print(f"Current torque: {data.torques.to_list()}")
    print(f"In mA: {data.torques.to_milliamps()}")

    # Set torque using mA
    torques = O6Torque.from_milliamps([1000.0] * 6)
    hand.torque.set_torques(torques)

Temperature Reading

Use hand.temperature to read the temperature of the 6 O6 joint motors in °C.

Temperature fields

Read Temperature

Blocking Read

data = hand.temperature.get_blocking(timeout_ms=500)
print(f"Thumb temperature: {data.temperatures.thumb_flex}°C")

Parameter

• timeout_ms: Timeout in milliseconds, default 100

Return value

• TemperatureData: Contains temperatures and timestamp

Exception

• TimeoutError: No response before timeout

Cached Read

Read the most recent cached temperature data without blocking.

data = hand.temperature.get_snapshot()
if data:
    print(f"Temperature: {data.temperatures.to_list()}")

Return value

• TemperatureData or None if no cached data is available

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, TemperatureEvent

hand.start_polling({SensorSource.TEMPERATURE: 0.1})

for event in hand.stream():
    match event:
        case TemperatureEvent(data=data):
            print(f"Temperature: {data.temperatures.to_list()}")

hand.stop_polling()
hand.stop_stream()

Examples

Read All Joint Temperatures

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    data = hand.temperature.get_blocking(timeout_ms=500)

    # Access by field
    print(f"Thumb flexion: {data.temperatures.thumb_flex}°C")
    print(f"Index finger: {data.temperatures.index}°C")

    # Convert to list
    temps = data.temperatures.to_list()
    print(f"All temperatures: {temps}")

    # Index access
    print(f"First joint motor: {data.temperatures[0]}°C")

Temperature Monitoring

from realhand import O6
from realhand.hand.o6 import SensorSource, TemperatureEvent

with O6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.TEMPERATURE: 0.1})

    try:
        for event in hand.stream():
            match event:
                case TemperatureEvent(data=data):
                    for i, temp in enumerate(data.temperatures.to_list()):
                        if temp > 60.0:
                            print(f"Warning: joint motor {i} is overheating ({temp}°C)")
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Force Sensors

The O6 dexterous hand is equipped with force sensors on 5 fingers (thumb, index, middle, ring, pinky). It supports both blocking and cached reads.

Overview

Use hand.force_sensor to access force sensor data:

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking()

Data Structures

ForceSensorData - sensor data for one finger:

• values: A NumPy array of shape (10, 4) with dtype uint8
• timestamp: Unix timestamp

AllFingersData - data for all 5 fingers:

• thumb, index, middle, ring, pinky: the ForceSensorData for each finger

Read Data

Blocking Read

data = hand.force_sensor.get_blocking(timeout_ms=1000)
print(data.thumb.values)  # Thumb data
print(data.index.values)  # Index data

Exceptions: TimeoutError (timeout), ValidationError (invalid parameter)

Cached Read

Get the most recently received data without blocking:

data = hand.force_sensor.get_snapshot()
if data:
    print(f"Thumb: {data.thumb.values[0]}")
    print(f"Index: {data.index.values[0]}")

Return value: AllFingersData or None if any finger is missing data

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, ForceSensorEvent

hand.start_polling({SensorSource.FORCE_SENSOR: 0.1})

for event in hand.stream():
    match event:
        case ForceSensorEvent(data=data):
            print(data.thumb.values)

hand.stop_polling()
hand.stop_stream()

Examples

Blocking Read for All Fingers

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    data = hand.force_sensor.get_blocking(timeout_ms=1000)
    print(f"Thumb: {data.thumb.values.shape}")
    print(f"Index: {data.index.values.shape}")

Stream for a Fixed Duration

import time
from realhand import O6
from realhand.hand.o6 import SensorSource, ForceSensorEvent

with O6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FORCE_SENSOR: 0.05})
    start = time.time()

    try:
        for event in hand.stream():
            match event:
                case ForceSensorEvent(data=data):
                    print(f"Thumb: {data.thumb.values[0]}")
            if time.time() - start > 5:  # Collect for 5 seconds
                break
    finally:
        hand.stop_polling()
        hand.stop_stream()

Fault Handling

Fault detection for the O6 dexterous hand.

Overview

Use hand.fault to access fault-related functionality:

• Read fault status in blocking or cached mode

Fault Code Table

Read Faults

Blocking Read

data = hand.fault.get_blocking(timeout_ms=500)

Parameter:

• timeout_ms: Timeout in milliseconds, default 100

Return value: FaultData, containing:

• faults: O6Fault fault data
• timestamp: Timestamp

Exception:

• TimeoutError: No response before timeout

Cached Read

data = hand.fault.get_snapshot()

Returns the latest cached fault data, or None if no data is available.

Streaming Read

Receive all sensor events through the top-level hand.stream() interface:

from realhand.hand.o6 import SensorSource, FaultEvent

hand.start_polling({SensorSource.FAULT: 0.2})

for event in hand.stream():
    match event:
        case FaultEvent(data=data):
            if data.faults.has_any_fault():
                for code in data.faults.to_list():
                    if code.has_fault():
                        print(code.get_fault_names())

hand.stop_polling()
hand.stop_stream()

Fault Data

O6Fault fields

O6Fault methods

# Check whether any fault exists
faults.has_any_fault()  # -> bool

# Convert to a list
faults.to_list()  # -> list[FaultCode]

# Index access
faults[0]  # thumb_flex

FaultCode methods

# Check whether a single joint motor has a fault
faults.thumb_flex.has_fault()  # -> bool

# Get fault names
faults.thumb_flex.get_fault_names()  # -> list[str]

Examples

Check Fault Status

from realhand import O6

with O6(side="left", interface_name="can0") as hand:
    # Read fault status
    data = hand.fault.get_blocking(timeout_ms=500)

    if data.faults.has_any_fault():
        print("Fault detected:")
        if data.faults.thumb_flex.has_fault():
            print(f"  Thumb flexion: {data.faults.thumb_flex.get_fault_names()}")
        if data.faults.index.has_fault():
            print(f"  Index finger: {data.faults.index.get_fault_names()}")
    else:
        print("No faults")

Continuous Monitoring

from realhand import O6
from realhand.hand.o6 import SensorSource, FaultEvent

with O6(side="left", interface_name="can0") as hand:
    hand.start_polling({SensorSource.FAULT: 0.2})

    try:
        for event in hand.stream():
            match event:
                case FaultEvent(data=data):
                    if data.faults.has_any_fault():
                        for code in data.faults.to_list():
                            if code.has_fault():
                                print(code.get_fault_names())
    except KeyboardInterrupt:
        pass
    finally:
        hand.stop_polling()
        hand.stop_stream()

Version Information

Read version information for the O6 dexterous hand.

Overview

Use hand.version to access version-related functionality:

• Read complete device information, including serial number and PCB / firmware / mechanical versions

Read Device Information

hand.version.get_device_info() -> DeviceInfo

Returns a DeviceInfo object containing:

The Version object has major, minor, and patch fields, and its string format is V{major}.{minor}.{patch}.

Exception:

• TimeoutError: Request timed out

Example

Read Device Information

from realhand import O6

hand = O6(side="left", interface_name="can0")

info = hand.version.get_device_info()
print(f"Serial number: {info.serial_number}")
print(f"PCB version: {info.pcb_version}")
print(f"Firmware version: {info.firmware_version}")
print(f"Mechanical version: {info.mechanical_version}")

hand.close()

A7 Lite Arm

Documentation for the A7 Lite arm.

Quick Start

from realhand import A7lite

with A7lite(
    side="left",
    interface_name="can0",
) as arm:
    arm.enable()  # Enable all 7 joint motors
    arm.home()  # Move the arm to the zero position
    arm.disable()  # Disable all 7 joint motors

Constructor Parameters

The constructor automatically checks whether all 7 motors are online.

Dependency requirement: A7 Lite relies on Pinocchio for kinematics. Install the optional kinetix dependency:

pip install "realhand[kinetix] @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

Windows users: Pinocchio does not support installation via pip on Windows. Use conda install pinocchio -c conda-forge.

Exceptions:

• ImportError: The optional kinetix dependency (Pinocchio) is not installed
• ValueError: Invalid side or world_frame argument
• StateError: Motors did not respond on the CAN bus / report data timed out

URDF paths: src/realhand/arm/kinetix/urdf/a7_lite__left.urdf and a7_lite__right.urdf

Coordinate Frames

A7 Lite supports two world coordinate frames selected by the world_frame parameter.

URDF Frame (default)

This is the coordinate system defined by the URDF model file. Its origin is at the midpoint of the line connecting the left and right shoulder joints, as shown below:

• X axis: Positive X points from the back of the robot toward the front
• Y axis: Positive Y points to the robot’s left side from the robot’s perspective (the viewer’s right when facing the robot)
• Z axis: Positive Z points upward by the right-hand rule
• Rx, Ry, Rz: Rotations are applied in Z, Y, X order, with counterclockwise as positive

Maestro Frame

The Maestro frame applies two transformations relative to the URDF frame, as shown below:

1. Origin translation: Moves the world origin from the base center to the center of Joint 2 (the second shoulder joint)
2. Rotate Z by 90°: Rotates the URDF axes counterclockwise by +90° around Z at the new origin

After the transformation:

• X axis: Positive X points to the robot’s right side from the robot’s perspective (the viewer’s left when facing the robot)
• Y axis: Positive Y points from the back of the robot toward the front
• Z axis: Positive Z points upward by the right-hand rule

Note: These coordinate definitions mainly affect the Pose values used by move_p and move_l. They do not affect move_j.

Joint Definition

Zero Position

When all joint angles are [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], the arm should be in a natural hanging pose with joints perpendicular to each other. Call home() to return to the zero position, shown below:

Positive Rotation Direction

Positive joint angles follow the right-hand rule: point your right thumb along the positive rotation axis, and the direction in which your fingers curl is the positive direction.

Because some URDF joint axes are negative (for example 0 -1 0), the actual positive direction may be opposite to intuition:

• Axis 0 -1 0 (negative Y): Increasing the angle rotates around negative Y, which appears clockwise when looking along the positive Y axis
• Axis -1 0 0 (negative X): Increasing the angle rotates around negative X, which appears clockwise when looking along the positive X axis
• Axis 0 0 1 (positive Z): Increasing the angle rotates around positive Z, which appears counterclockwise when viewed from above

A7 Lite Left Arm Joint List (URDF frame)

A7 Lite Right Arm Joint List (URDF frame)

Pose (TCP Pose) Representation

Pose represents the TCP (Tool Center Point) pose. It is a Pydantic model with 6 fields:

from realhand import Pose

pose = Pose(x=0.3, y=0.1, z=0.5, rx=0.0, ry=0.5, rz=0.0)

• Orientation uses extrinsic ZYX Euler angles: rotate around the world Z axis by rz, then the world Y axis by ry, and finally the world X axis by rx.

Lifecycle Management

API Reference

Notes

1. Calling arm.enable() causes a brief disable/enable cycle.
2. The arm must be disabled before setting the zero position.
3. emergency_stop() is blocking and waits for about 2 seconds.

Control Mode

Only PP (Profile Position) mode is currently supported. It is configured automatically when enable() is called.

You can import the ControlMode enum from realhand:

from realhand import ControlMode

CAN Bus

interface_name specifies the CAN interface name (for example "can0"), and interface_type specifies the interface type (default "socketcan").

For more information, including Windows usage, see CAN Bus Configuration.

Functional Modules

Motion Control

Homing

Move all joints to the zero position ([0.0] * 7).

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.home()  # Blocking mode
    arm.home(blocking=False)  # Non-blocking mode

Parameter:

• blocking: Whether to block until motion completes. Default is True.

move_j

Move the arm by sending target joint angles for each joint.

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=True)

Parameters:

• target_joints: Target angles for the 7 joints in radians, type list[float]
• blocking: Whether to block until motion completes, default True, type bool

Exceptions:

• StateError: Called again while the arm is already moving
• ValidationError: Target angles exceed joint limits

move_p

Move the arm by sending a TCP 6D pose (x, y, z, rx, ry, rz). The SDK first solves inverse kinematics and then executes joint motion. The end-effector path is not guaranteed to be a straight line.

from realhand import A7lite
from realhand import Pose

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    target = Pose(x=0.3, y=0.1, z=0.5, rx=0.0, ry=0.5, rz=0.0)
    arm.move_p(target)

Parameters:

• target_pose: Target TCP pose, type Pose
• current_angles: Initial IK guess for joint angles, type list[float] | None; when None, the SDK reads the motors
• blocking: Whether to block until motion completes, type bool, default True

Exceptions:

• StateError: Called again while the arm is already moving
• RuntimeError: IK solving failed

move_l

Move the arm in a straight line by sending a TCP 6D pose (x, y, z, rx, ry, rz). The end effector follows a straight Cartesian path. Position uses trapezoidal velocity planning, and orientation uses spherical linear interpolation (Slerp). move_l always blocks until motion completes and therefore has no blocking parameter.

from realhand import A7lite, Pose

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_l(target, max_velocity=0.1, acceleration=0.2)

Parameters:

• target_pose: Target TCP pose, type Pose
• max_velocity: Maximum linear speed for TCP trapezoidal planning in m/s, default 0.05, range (0, 0.4]
• max_angular_velocity: Maximum angular speed for TCP rotation planning in rad/s, default 0.3, range (0, 3.0]
• acceleration: Maximum linear acceleration for TCP trapezoidal planning in m/s², default 0.1, range (0, 1.0]
• angular_acceleration: Maximum angular acceleration for TCP rotation planning in rad/s², default 0.1, range (0, 1.0]
• current_pose: Starting TCP pose. If None, it is computed from current_angles or by reading the motors. Type Pose | None
• current_angles: Starting joint angles. If None, they are read from the motors. Type list[float] | None

Exceptions:

• StateError: Called again while the arm is already moving
• ValidationError: A parameter is out of range
• RuntimeError: IK failed for a path waypoint

Motion Status

Returns whether the arm is currently moving.

if arm.is_moving():
    print("Arm is moving...")

Return value:

• bool: Whether the arm is moving

Wait for Motion Completion

Block the current thread until the motion timer reaches zero. This is typically used together with blocking=False.

arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=False)
# ... do other work ...
arm.wait_motion_done()  # Wait for motion to finish

Examples

Non-Blocking Motion and Waiting

from realhand import A7lite, Pose

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.home()

    # Non-blocking move_j: returns immediately after sending the command
    arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=False)
    print("move_j sent, arm is moving...")
    arm.wait_motion_done()  # Wait until the motion completes

    # Blocking move_p: returns only after motion is done
    target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_p(target)

    # move_l is always blocking
    target = Pose(x=0.1, y=0.33, z=-0.2, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_l(target, max_velocity=0.1, acceleration=0.2)

    arm.home()

Kinematics

Forward Kinematics

Compute the TCP pose from joint angles.

pose = arm.forward_kinematics([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0])
print(f"TCP: ({pose.x:.3f}, {pose.y:.3f}, {pose.z:.3f})")

Parameter:

• angles: 7 joint angles in radians, type list[float]

Return value:

• Pose: TCP pose

Inverse Kinematics

Solve joint angles from a TCP pose.

from realhand import Pose

target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
angles = arm.inverse_kinematics(target)
print(f"Joint angles: {angles}")

Parameters:

• pose: Target TCP pose, type Pose
• current_angles: Initial IK guess for joint angles, type list[float] | None; when None, the SDK reads the motors

Return value:

• list[float]: 7 joint angles in radians

Joint Limits

# Read the current joint limits
limits = arm.get_joint_limits()
print(limits)  # [(lower0, upper0), (lower1, upper1), ...]

# Set custom joint limits
arm.set_joint_limits([(-1.0, 1.0)] * 7)

State Reading

Full State Snapshot

Read the complete arm state in one call, including TCP pose plus angle, velocity, acceleration, torque, and temperature for all joints.

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    state = arm.get_state()
    print(state.pose)
    print(f"Actual angle of the first joint: {state.joint_angles[0].angle:.4f} rad")

Return value

• State: Contains pose, joint_angles, joint_control_angles, joint_velocities, joint_control_velocities, joint_control_acceleration, joint_torques, and joint_temperatures

State data model

Each sub-state model (AngleState, VelocityState, etc.) includes a value field and a timestamp (Unix time in seconds).

Sub-state model fields

Read Individual State Items

Besides get_state(), the following methods return a single kind of state. All of them return lists for 7 joints, except get_pose().

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    angles = arm.get_angles()
    velocities = arm.get_velocities()
    temps = arm.get_temperatures()
    pose = arm.get_pose()
    print(f"Actual angle of the second joint: {angles[1]:.4f} rad")
    print(f"Actual velocity of the third joint: {velocities[2]:.4f} rad/s")
    print(f"Actual temperature of the fourth joint: {temps[3]:.1f} °C")
    print(f"TCP: ({pose.x:.3f}m, {pose.y:.3f}m, {pose.z:.3f}m)")

Return values

Sensor Data

A7 Lite uses active motor reporting mode, which starts automatically during construction.

Configuration

Speed and Acceleration Limits

Set speed and acceleration limits for the 7 joints. These affect motions such as move_j and move_p.

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.enable()
    # Set the speed limit of all joints to 2.0 rad/s
    arm.set_velocities([2.0] * 7)
    # Set acceleration limits individually
    arm.set_accelerations([10.0, 9.0, 8.0, 7.0, 6.0, 5.0, 4.0])

Exception: ValidationError (exactly 7 values are required, and all values must be within range)

PID Parameter Settings

Set PID parameters for the 7 joints.

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.set_position_kps([100.0] * 7)
    arm.set_velocity_kps([0.5] * 7)
    arm.set_velocity_kis([0.01] * 7)
    arm.set_velocity_filt_gains([0.8] * 7)

Parameter Quick Reference

Example

Set PID, Speed, and Acceleration Limits

from realhand import A7lite

with A7lite(side="left", interface_name="can0") as arm:
    arm.set_position_kps([80.0] * 7)
    arm.set_velocity_kps([0.4] * 7)
    arm.set_velocity_kis([0.008] * 7)
    arm.set_velocity_filt_gains([0.9] * 7)
    arm.set_velocities([1.0] * 7)
    arm.set_accelerations([5.0] * 7)

A7 Arm

A7 is a self-developed 7-DoF robotic arm.

Quick Start

from realhand import A7

with A7(
    side="left",
    interface_name="can0",
) as arm:
    arm.enable()  # Enable all 7 joint motors
    arm.home()  # Move the arm to the zero position
    arm.disable()  # Disable all 7 joint motors

Constructor Parameters

The constructor automatically checks whether all 7 motors are online.

Dependency requirement: A7 relies on Pinocchio for kinematics. Install the optional kinetix dependency:

pip install "realhand[kinetix] @ git+https://github.com/RealHand-Robotics/realbot-python-sdk.git"

Windows users: Pinocchio does not support installation via pip on Windows. Use conda install pinocchio -c conda-forge.

Exceptions:

• ImportError: The optional kinetix dependency (Pinocchio) is not installed
• ValueError: Invalid side or world_frame argument
• StateError: Motors did not respond on the CAN bus / initial data read failed

URDF paths: src/realhand/arm/kinetix/urdf/a7__left.urdf and a7__right.urdf

Coordinate Frames

A7 supports two world coordinate frames selected by the world_frame parameter.

URDF Frame (default)

This is the coordinate system defined by the URDF model file. Its origin is at the center of the arm base (Base_Link), as shown below:

• X axis: Positive X points from the back of the robot toward the front
• Y axis: Positive Y points to the robot’s left side from the robot’s perspective (the viewer’s right when facing the robot)
• Z axis: Positive Z points upward by the right-hand rule
• Rx, Ry, Rz: Rotations are applied in Z, Y, X order, with counterclockwise as positive

Maestro Frame

The Maestro frame applies two transformations relative to the URDF frame, as shown below:

1. Origin translation: Moves the world origin from the base center to the center of Joint 2 (the second shoulder joint)
2. Rotate Z by 90°: Rotates the URDF axes counterclockwise by +90° around Z at the new origin

After the transformation:

• X axis: Positive X points to the robot’s right side from the robot’s perspective (the viewer’s left when facing the robot)
• Y axis: Positive Y points from the back of the robot toward the front
• Z axis: Positive Z points upward by the right-hand rule

Note: These coordinate definitions mainly affect the Pose values used by move_p and move_l. They do not affect move_j.

Joint Definition

Zero Position

When all joint angles are [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], the arm should be in a natural hanging pose with joints perpendicular to each other. Call home() to return to the zero position, shown below:

Positive Rotation Direction

Positive joint angles follow the right-hand rule: point your right thumb along the positive rotation axis, and the direction in which your fingers curl is the positive direction.

• Axis 0 1 0 (positive Y): Angle increases rotate counterclockwise when viewed along +Y
• Axis 1 0 0 (positive X): Angle increases rotate counterclockwise when viewed along +X
• Axis 0 0 -1 (negative Z): Angle increases rotate clockwise when viewed from above
• Axis 0 -1 0 (negative Y): Angle increases rotate clockwise when viewed along +Y

A7 Left Arm Joint List (URDF frame)

A7 Right Arm Joint List (URDF frame)

Pose (TCP Pose) Representation

Pose represents the TCP (Tool Center Point) pose. It is a Pydantic model with 6 fields:

from realhand import Pose

pose = Pose(x=0.3, y=0.1, z=0.5, rx=0.0, ry=0.5, rz=0.0)

• Orientation uses extrinsic ZYX Euler angles: rotate around the world Z axis by rz, then the world Y axis by ry, and finally the world X axis by rx.

Lifecycle Management

API Reference

Notes

1. Calling arm.enable() causes a brief disable/enable cycle.
2. The arm must be disabled before setting the zero position.

Control Mode

Only PP (Profile Position) mode is currently supported. It is configured automatically when enable() is called.

You can import the ControlMode enum from realhand:

from realhand import ControlMode

CAN Bus

interface_name specifies the CAN interface name (for example "can0"), and interface_type specifies the interface type (default "socketcan").

For more information, including Windows usage, see CAN Bus Configuration.

Functional Modules

Motion Control

Homing

Move all joints back to the zero position.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.home()  # Blocking mode
    arm.home(blocking=False)  # Non-blocking mode

Parameter:

• blocking: Whether to block until motion completes. Default is True.

move_j

Move the arm by sending target joint angles for each joint.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0])

Parameters:

• target_joints: Target angles for the 7 joints in radians, type list[float]
• blocking: Whether to block until motion completes, default True, type bool

Exceptions:

• StateError: Called again while the arm is already moving
• ValidationError: Target angles exceed joint limits

move_p

Move the arm by sending a TCP 6D pose (x, y, z, rx, ry, rz). The SDK first solves inverse kinematics and then executes joint motion. The end-effector path is not guaranteed to be a straight line.

from realhand import A7, Pose

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_p(target)

Parameters:

• target_pose: Target TCP pose, type realhand.arm.Pose
• current_angles: Initial IK guess for joint angles, type list[float] | None; when None, the SDK reads the motors
• blocking: Whether to block until motion completes, type bool, default True

Exceptions:

• StateError: Called again while the arm is already moving
• RuntimeError: IK solving failed

move_l

Move the arm in a straight line by sending a TCP 6D pose (x, y, z, rx, ry, rz). The end effector follows a straight Cartesian path. Position uses trapezoidal velocity planning, and orientation uses spherical linear interpolation (Slerp). move_l always blocks until motion completes and therefore has no blocking parameter.

from realhand import A7, Pose

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_l(target)

Parameters:

• target_pose: Target TCP pose, type Pose
• max_velocity: Maximum linear speed for TCP trapezoidal planning in m/s, default 0.05, range (0, 0.4]
• max_angular_velocity: Maximum angular speed for TCP rotation planning in rad/s, default 0.3, range (0, 3.0]
• acceleration: Maximum linear acceleration for TCP trapezoidal planning in m/s², default 0.1, range (0, 1.0]
• angular_acceleration: Maximum angular acceleration for TCP rotation planning in rad/s², default 0.1, range (0, 1.0]
• current_pose: Starting TCP pose. If None, it is computed from current_angles or by reading the motors. Type Pose | None
• current_angles: Starting joint angles. If None, they are read from the motors. Type list[float] | None

Exceptions:

• StateError: Called again while the arm is already moving
• ValidationError: A parameter is out of range
• RuntimeError: IK failed for a path waypoint

Motion Status

Returns whether the arm is currently moving.

if arm.is_moving():
    print("Arm is moving...")

Return value:

• bool: Whether the arm is moving

Wait for Motion Completion

Block the current thread until the motion timer reaches zero. This is typically used together with blocking=False.

arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=False)
# ... do other work ...
arm.wait_motion_done()  # Wait for motion to finish

Examples

Non-Blocking Motion and Waiting

from realhand import A7, Pose

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    arm.home()

    # Set speed and acceleration
    arm.set_velocities([1.0] * 7)
    arm.set_accelerations([10.0] * 7)

    # Non-blocking move_j: returns immediately after sending the command
    arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=False)
    print("move_j sent, arm is moving...")
    arm.wait_motion_done()  # Wait until the motion completes

    # Blocking move_p: returns only after motion is done
    target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_p(target)

    # move_l is always blocking
    target = Pose(x=0.1, y=0.33, z=-0.2, rx=1.85, ry=0.0, rz=-1.57)
    arm.move_l(target)

    arm.home()

Kinematics

Forward Kinematics

Compute the TCP pose from joint angles.

pose = arm.forward_kinematics([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0])
print(f"TCP: ({pose.x:.3f}, {pose.y:.3f}, {pose.z:.3f})")

Parameter:

• angles: 7 joint angles in radians, type list[float]

Return value:

• Pose: TCP pose

Inverse Kinematics

Solve joint angles from a TCP pose.

from realhand import Pose

target = Pose(x=0.0, y=0.33, z=-0.25, rx=1.85, ry=0.0, rz=-1.57)
angles = arm.inverse_kinematics(target)
print(f"Joint angles: {angles}")

Parameters:

• pose: Target TCP pose, type Pose
• current_angles: Initial IK guess for joint angles, type list[float] | None; when None, the SDK reads the motors

Return value:

• list[float]: 7 joint angles in radians

Joint Limits

# Read the current joint limits
limits = arm.get_joint_limits()
print(limits)  # [(lower0, upper0), (lower1, upper1), ...]

# Set custom joint limits
arm.set_joint_limits([(-1.0, 1.0)] * 7)

State Reading

Full State Snapshot

Read the complete arm state in one call, including TCP pose plus angle, velocity, acceleration, torque, and temperature for all joints.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    state = arm.get_state()
    print(state.pose)
    print(f"Actual angle of the first joint: {state.joint_angles[0].angle:.4f} rad")

Return value

• State: Contains pose, joint_angles, joint_control_angles, joint_velocities, joint_control_velocities, joint_control_acceleration, joint_torques, and joint_temperatures

State data model

Each sub-state model includes a value field and a timestamp (Unix time in seconds).

Sub-state model fields

Read Individual State Items

Besides get_state(), the following methods return a single kind of state. All of them return lists for 7 joints, except get_pose().

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    angles = arm.get_angles()
    velocities = arm.get_velocities()
    temps = arm.get_temperatures()
    pose = arm.get_pose()
    print(f"Actual angle of the second joint: {angles[1]:.4f} rad")
    print(f"Actual velocity of the third joint: {velocities[2]:.4f} rad/s")
    print(f"Actual temperature of the fourth joint: {temps[3]:.1f} °C")
    print(f"TCP: ({pose.x:.3f}m, {pose.y:.3f}m, {pose.z:.3f}m)")

Return values

Sensor Data

A7 uses polling to collect sensor data. get_*() returns the value from the latest polling cycle.

If you need lower latency, use start_polling() to configure different intervals for different sensor types:

from realhand import A7
from realhand.arm.a7 import SensorType

with A7(side="left", interface_name="can0") as arm:
    arm.start_polling(
        {
            SensorType.POSITION: 0.005,  # 5 ms = 200 Hz
            SensorType.VELOCITY: 0.005,
            SensorType.TORQUE: 0.1,
            SensorType.TEMPERATURE: 2.0,
        }
    )
    arm.enable()
    arm.home()

Configuration

Speed and Acceleration Limits

Set speed and acceleration limits for the 7 joints.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.enable()
    # Set the speed limit of all joints to 1.0 rad/s
    arm.set_velocities([1.0] * 7)
    # Set acceleration limits individually
    arm.set_accelerations([10.0, 9.0, 8.0, 7.0, 6.0, 5.0, 4.0])

Exception: ValidationError (exactly 7 values are required, and all values must be within range)

PID Parameter Settings

Set PID parameters for the 7 joints.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.set_position_kps([100.0] * 7)
    arm.set_velocity_kps([0.5] * 7)
    arm.set_velocity_kis([0.01] * 7)

Parameter Quick Reference

Example

Move After Setting PID, Speed, and Acceleration Limits

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.set_position_kps([80.0] * 7)
    arm.set_velocity_kps([0.4] * 7)
    arm.set_velocity_kis([0.008] * 7)
    arm.enable()
    arm.set_velocities([1.0] * 7)
    arm.set_accelerations([10.0] * 7)
    arm.home(blocking=True)
    arm.move_j([0.0, 0.0, 0.0, 1.57, 0.0, 0.0, 0.0], blocking=True)

Parameter Persistence

Call save_params() to write the current PID, speed, acceleration, and related parameters to motor flash so they remain effective after power loss.

from realhand import A7

with A7(side="left", interface_name="can0") as arm:
    arm.set_position_kps([80.0] * 7)
    arm.set_velocity_kps([0.4] * 7)
    arm.save_params()  # Save to flash

Note: Each write takes about 1 ms. Avoid calling this in real-time control loops.
